Sony HCD-DX2D - Front Panel Section; MAIN Board

14
HCD-DX2D
3-9. MAIN BOARD
3-8. FRONT PANEL SECTION
6 cla
w
7 claw
8 front panel section
1 two screws
(screw 3
× 10)
2 screw
(screw 3
× 8)
3 screw
(screw 3
× 8)
5 connector
8P (CN201)
4 wire (flat type)
23core (CN501)
3 connector
8P (CN201)
4 connector
11P (FW901)
2 wire (flat type)
23core (CN501)
6 wire (flat type)
9core (CN203) (EXCEPT AEP, UK)
11core (CN203) (AEP, UK)
5 wire (flat type)
12core (CN503)
1 two screws
(screw 3
× 10)
7 MAIN board
Ver. 1.1
