7
HCD-DX2D
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Main unit
Cassette compartment qh (31)
CD SYNC 0 (31)
Disc tray 5 (14)
DISPLAY 9 (30, 37, 38, 39)
Display window 3
PHONES jack qk
PLAY MODE wd (15, 19, 48)
PRESET EQ ws (33)
PROGRESSIVE wa (24)
Remote sensor 4
TUNER/BAND 7 (28, 29, 32)
TUNING +/– qs (28, 30)
TV w; (32, 42)
VOLUME control qj (42)
?/1 (on/standby) 1 (11, 48)
TAPE N (play) 2 (31)
DVD NX (play/pause) 6 (14,
32, 43, 48)
Z (open/close) 8 (14)
z REC PAUSE/START (record)
qa (31, 34)
m/M (rewind/fast forward)
qs (15, 31)
./> (go back/forward) qs
(15, 31)
Z PUSH OPEN/CLOSE (eject)
qd (31)
x (stop) ql (12, 15, 24, 29, 31,
32, 34, 43, 48)
List of button locations and reference pages
How to use this page
Use this page to find the location of buttons and other
parts of the system that are mentioned in the text.
Illustration number
r
TUNER/BAND 7 (28, 29, 32)
RR
Name of button/part Reference page
ALPHABETICAL ORDER
A – O P – Z
BUTTON DESCRIPTIONS
