HCD-DX2D
• CAUTION ON HANDLING POWER CORD (SAFETY STANDARD)
• PRECAUTION WHEN REPLACING THE CAP
When you remove or replace the power cord,
(1) Fix the power cord to the POWER board with a binding strap as before.
(2) Check that the single-sheathed portion of the power cord does not contact the transformer
even when the single-sheathed portion is pushed toward the transformer with a 200-g force.
single-sheathed portion
of the power cord
power transformer
Please apply the adhesive agent or attach the double-sided tape to the BASE KEY POWER when replacing the CAP KEY POWER.
Please apply the adhesive agent or attach the double-sided tape to the BASE KEY OPEN when replacing the CAP KEY OPEN.
CAP KEY POWER
CAP KEY OPEN
BASE KEY OPEN
BASE KEY POWER
