Sony HCD-DX2D - Printed Wiring Board - MAIN Section

2626
HCD-DX2D
HCD-DX2D
7-5. PRINTED WIRING BOARD — MAIN SECTION —
• See page 21 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D105 G-9
D106 C-10
D107 C-10
D196 B-9
D198 B-8
D199 B-8
D301 I-5
D302 I-3
D305 G-5
D306 I-3
D307 I-2
D308 H-3
D309 J-4
D310 H-2
D312 G-9
D313 G-5
D314 G-9
D317 G-9
D318 G-2
D319 F-7
D320 F-7
D321 F-7
D322 F-7
D323 I-7
D324 J-4
D325 H-4
D326 F-8
D327 F-8
D328 C-8
D329 D-8
D330 C-8
D501 G-5
D502 D-3
D503 C-3
D505 D-2
D507 F-5
D508 H-3
IC301 H-5
IC302 F-4
IC501 B-4
IC502 C-3
IC503 D-5
Q196 B-9
Q197 B-9
Q198 B-8
Q199 B-9
Q305 J-4
Q306 I-2
Q307 H-3
Q313 G-8
Q315 I-3
Q316 H-3
Q317 H-5
Q318 G-5
Q319 J-3
Q320 J-4
Q321 G-5
Q322 G-5
Q326 G-3
Q327 G-3
Q328 G-3
Q329 G-3
Q330 G-3
Q331 G-3
Q332 G-3
Q344 F-2
Q345 F-3
Q346 E-3
Q347 D-3
Q348 E-3
Q502 C-3
Q504 D-3
Q505 D-3
Q506 D-3
Q507 C-3
IC301
IC503
IC302
IC501
IC502
SFTY
C123
C223
AEP,UK
MAIN BOARD
L
R
IN
TV
JK201
+
–
–
+
L
SPEAKER
IMPEDANCE USE 6Ω
R
JK102
C
MPEG BOARD
CN3
(Page 31)
E
AMP BOARD
CN106
(Page 39)
H
AMP BOARD
CN108
(Page 39)
I
AMP BOARD
CN102
(Page 39)
(CHASSIS)
A
KEY BOARD
CN601
(Page 35)
HEAD
(REC/PLAYBACK/ERASE)
L-CH
R-CH
ERASE
HEAD
REC/PB
HEAD
1
2
3
4
6
8
7
5
D
POWER BOARD
FW901
US,CND (Page 41)
AEP,UK (Page 43)
1
AEP,UK
2
8
9
11
10
TUNER
B
for DOWN LOAD
MPEG BOARD
CN1
(Page 31)
1
1
16
17
32
33
48
49
64
28
7
1
11
2
12
1
9
3
1
1
10
7
1
E
1
2
23
22
E
E
E
E
E
E
8
1
E
E
E
1
11
5
1
E
1
4
5
8
1
4
5
8
E
E
E
E
E
E
s
s
s
EE
E
E
E
E
A
A
A
K
K
K
E
E
E
E
E
E
E
TAPE
MECHANISM
DECK
12
A
B
C
D
E
G
H
I
J
34567891011
F
