60
HCD-DX2D
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
•Abbreviation
AUS: Australian model
CND : Canadian model
E3 : 240 V AC Area in E model
E51 : Chilean and Peruvian models
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP BOARD
**********
< IC >
IC103 6-705-621-01 IC STK433-070
*************************************************************
AV BOARD (EXCEPT AEP, UK, RU)
*********
*************************************************************
AV BOARD (AEP, UK, RU)
*********
< IC >
IC801 9-885-104-48 IC MM1623 (AEP, UK, RU)
< CONNECTOR >
JK802 9-885-061-75 CONNECTOR 21P (LINE-TV)(AEP, UK, RU)
< SWITCH >
S801 9-885-104-50 SLIDE SWITCH (EURO AV - COMPONENT)
(AEP, UK, RU)
*************************************************************
9-885-100-92 KEY BOARD, COMPLETE (including HP BOARD)
********************
< IC >
IC651 8-759-643-83 IC uPD16315GB-3BS
IR651 6-701-681-01 IC RPM7140-V4
< FLUORESCENT INDICATOR TUBE >
VFD651 1-519-761-31 INDICATOR TUBE, FLUORESCENT
< ROTARY ENCODER >
VR601 9-885-100-93 ROTARY ENCODER EC121102X2 (VOLUME)
HP BOARD
*********
< JACK >
JK103 9-885-077-12 MIC JACK DIA:3.5MM BLACK (PHONES)
************************************************************
9-885-100-89 MAIN BOARD, COMPLETE (US, CND)
9-885-104-51 MAIN BOARD, COMPLETE (AEP, UK)
(Refer to SUPPLEMENT-1 about EXCEPT US, CND, AEP and UK)
*********************
< IC >
IC301 9-885-059-44 IC AP1501
IC302 6-702-895-01 IC BD3881FV
IC502 9-885-100-91 IC BD4736G
IC503 9-885-100-90 IC AT24C0
< TERMINAL BOARD >
JK102 9-885-104-49 TERMINAL BOARD (SPEAKER)
< JACK >
JK201 9-885-059-87 JACK, PIN 4P (TV)
< TRANSFORMER >
T301 9-885-059-58 OSCILLATION, BIAS TRANSFORMER
< VIBRATOR >
X501 9-885-059-48 VIBRATOR, CRYSTAL (32.768kHz)
X502 9-885-059-52 OSCILLATOR, CERAMIC (8.38MHz)
*************************************************************
9-885-100-94 MPEG BOARD, COMPLETE (US, CND)
9-885-104-52 MPEG BOARD, COMPLETE (AEP, UK)
9-885-105-69 MPEG BOARD, COMPLETE (E3)
9-885-105-70 MPEG BOARD, COMPLETE (AUS)
9-885-105-71 MPEG BOARD, COMPLETE (SP, KR, TH)
9-885-107-30 MPEG BOARD, COMPLETE (RU)
9-885-107-88 MPEG BOARD, COMPLETE (E51)
*********************
< IC >
IC4 9-885-100-98 IC K4S161622H
IC5 9-885-100-98 IC K4S161622H
IC7 9-885-100-95 IC AM5888S
IC8 8-759-909-71 IC BA4558F
IC14 9-885-100-90 IC AT24C0
U2 9-885-100-96 IC ZR36862 TQFP-208
< VIBRATOR >
Y1 9-885-059-78 VIBRATOR, CRYSTAL (27MHz)
************************************************************
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
AMP AV KEY
MAIN MPEG
HP
KR : Korean model
RU : Russian model
SP : Singapore model
TH : Thai model
Ver. 1.2
