54
HCD-DX2D
Pin No. Pin Name I/O Description
154 RSET I Connected to ground
155 GNDDACP — Ground terminal
156 GNDDACBS2 — Ground terminal
157 RF P I Main-beam RF signal input
158 RF N I Not used
159 G I DC coupled main-beam RF signal input G (not used)
160 A I DC coupled main-beam RF signal input A
161 AVDD1 — Power supply terminal (+3.3V)
162 B I DC coupled main-beam RF signal input B
163 SVDD — Power supply terminal (+3.3V)
164 AVDD — Power supply terminal (+3.3V)
165 C I DC coupled main-beam RF signal input C
166 H I DC coupled main-beam RF signal input H (not used)
167 D I DC coupled main-beam RF signal input D
168 J — Not used
169 AGND — Ground terminal
170 E I DC coupled main-beam RF signal input E
171 K — Not used
172 F I DC coupled main-beam RF signal input F
173 VC I Control signal input from Optical pick-up
174 VBCAP — Connected to +3.3V
175 RESOUT I Connected to ground
176 CD_MD O Volume control signal output to Optical pick-up
177 DVD_MD O Volume control signal output to Optical pick-up
178 CD_LD O Laser drive output
179 DVD_LD O Laser drive output
180 AGND — Ground terminal
181 AGND1 — Ground terminal
182 VDDC — Power supply terminal (+1.8V)
183 I032 O Motor Drive AMP signal output
184 GNDC — Ground terminal
185 ICI04 I SW (close) signal input
186 ICI05 I SW (open) signal input
187 VDDP — Power supply terminal (+3.3V)
188 IDI03 O Laser select drive output
189 GNDP — Ground terminal
190 ICI06 — Not used
191 ICI07 — Not used
192 VDD-IP — Power supply terminal (+3.3V)
193 IDI06/SLED — Not used
194 IDI07/SPINDLE — Not used
195 I043/PWMCO2 O Motor Drive AMP signal output
196 I044/PWMCO3 O Motor Drive AMP signal output (not used)
197 GNDPWM — Ground terminal
198 I045/PWMCO4 O Motor Drive AMP signal output
199 VDDPWM — Power supply terminal (+3.3V)
200 I046/PWMCO5 I HOME SW signal input
201 IDI04/PWMCO6 O Motor Drive AMP signal output
202 I04/PWMCO0 O Motor Drive AMP signal output
