Sony HCD-GN660 - Primary Board; Rear Panel

12
HCD-GN660/GN770/GX9000
3-10. PRIMARY BOARD
3-11. REAR PANEL
6 bracket, sub
4 bracket, top
qa CN201
qs PRIMARY board
9 connector
0 CN101
7 CN1002
1 two screws
(BVTP3 x 10)
5 two screwss
(BVTP3 x 6)
2 four screws
(BVTP3 x 6
)
8 connector
3 two screws
(+BVTT3 x 6)
1 nine screws
(+BVTP3 x 10)
2 screw
(+BVTT3 x 6)
4 Connector
CN503
MAIN board
3 rear panel
with fan
