Sony HCD-GN660 - BD Board, Optical Pick-Up (KSM-215 DCP;C2 NP); Sensor Board

15
HCD-GN660/GN770/GX9000
3-16. BD BAORD, OPTICAL PICK-UP (KSM-215DCP/C2NP)
3-17. SENSOR BOARD
5 two coil springs
(insulator)
9 two coil springs
(insulator)
6 two insulators
0 two insulators
qs s crew (+BVTP 2.6x 8)
7 t wo screws
(BVTT M2.6)
3 screw
(BVTT M2.6)
2 h older (213) ASSY
8 t wo stoppers (BU)
qd Remove the four solderings of motor.
qf CN101 (flat type)
qg B D board
qh optical pick-up
(KSM-215DCP/C2NP)
1 floating screw
(+PTPWH M2.6)
4 floating screw
(+PTPWH M2.6)
qa
2 t ray
3 b elt (table)
5 p ulley (table)
8 s crew
(+BTTP (M2.6))
0 SENSOR board
7 g ear (geneva)
9 connector
( CN731)
1 floating screw
(+PTPWH M2.6)
6 floating screw
(+PTPWH M2.6)
4 floating screw
(+PTPWH M2.6)
