Sony HCD-GN660 - Circuit Board Location

26
HCD-GN660/GN770/GX9000
7-1. CIRCUIT BOARD LOCATION
TUNER PACK
PRIMARY board
SURROUND boar
d
PA board
SWITCHING POWER
PANEL board
SWITCH board
GAME board
MOTOR (LD) board
SW board
SENSOR board
JOG board
BD board
MOTOR (TB) board
DRIVER board
MAIN board
CD SW board
