53
HCD-GN660/GN770/GX9000
Pin No Pin Name I/O Description
98 SBSO O Subcode P to W serial output (Not used)
99 EXCK I SBSO readout clock input (Not used)
100 XRST I System reset input
101 SYSM I Mute input
102 D ATA I Serial data input from CPU
103 VSS — Internal digital ground
104 XLAT I Latch input from CPU
105 CLOCK I Serial data transfer clock input from CPU
106 VDD — Sled drive output Internal digital power supply Tracking drive output
107 SENS O SENS output to CPU
108 SCLK I SENS serial data readout clock input
109 ATSK I/O Anti-shock input/output (Not used)
110WFCK O WFCK output (Not used)
111 XUGF O XUGF output (Not used)
112XPCK O XPCK output (Not used)
113 GFS O GFS output (Not used)
114C2PO O C2PO output (Not used)
115 SCOR O High output when the subcode sync, S0 or S1, is detected
116 VDD — Internal digital power supply
117 C4M O 4 2336MHz output (Not used)
118WDCK O Word clock output f = 2Fs (Not used)
119 COUT I/O Track number count signal input/output (Not used)
120 NC — Not used
