67
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
< JACK >
J501 1-770-272-11 JACK, PIN 2P (VIDEO/MD (AUDIO))
J504 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< SHORT >
JR102 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR111 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-864-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-864-11 SHORT CHIP 0
JR116 1-216-296-11 SHORT CHIP 0
JR117 1-216-864-11 SHORT CHIP 0
JR118 1-216-864-11 SHORT CHIP 0
JR119 1-216-864-11 SHORT CHIP 0
JR120 1-216-864-11 SHORT CHIP 0
JR121 1-216-864-11 SHORT CHIP 0
JR122 1-216-864-11 SHORT CHIP 0
JR207 1-216-296-11 SHORT CHIP 0
JR231 1-216-864-11 SHORT CHIP 0
JR233 1-216-864-11 SHORT CHIP 0
JR234 1-216-864-11 SHORT CHIP 0
JR236 1-216-864-11 SHORT CHIP 0
JR237 1-216-864-11 SHORT CHIP 0
JR238 1-216-864-11 SHORT CHIP 0
JR240 1-216-864-11 SHORT CHIP 0
JR241 1-216-864-11 SHORT CHIP 0
JR243 1-216-864-11 SHORT CHIP 0
JR244 1-216-296-11 SHORT CHIP 0
JR245 1-216-864-11 SHORT CHIP 0
JR246 1-216-864-11 SHORT CHIP 0
JR247 1-216-864-11 SHORT CHIP 0
JR248 1-216-864-11 SHORT CHIP 0
JR249 1-216-864-11 SHORT CHIP 0
JR251 1-216-864-11 SHORT CHIP 0
JR252 1-216-864-11 SHORT CHIP 0
JR253 1-216-864-11 SHORT CHIP 0
JR254 1-216-864-11 SHORT CHIP 0
JR256 1-216-296-11 SHORT CHIP 0
JR257 1-216-864-11 SHORT CHIP 0
JR258 1-216-296-11 SHORT CHIP 0
JR259 1-216-864-11 SHORT CHIP 0
JR260 1-216-296-11 SHORT CHIP 0
JR330 1-216-296-11 SHORT CHIP 0
JR331 1-216-864-11 SHORT CHIP 0
JR333 1-216-864-11 SHORT CHIP 0 (GN660/GN770)
JR503 1-216-864-11 SHORT CHIP 0
JR732 1-216-864-11 SHORT CHIP 0
JR874 1-216-864-11 SHORT CHIP 0
JR879 1-216-864-11 SHORT CHIP 0
JR882 1-216-864-11 SHORT CHIP 0
< COIL >
L103 1-410-780-11 INDUCTOR 27mH
L104 1-410-780-11 INDUCTOR 27mH
L105 1-414-189-31 INDUCTOR 100uH
< CONNECTOR >
* NO504 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
(GN660/GX9000)
< TRANSISTOR >
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-802-80 TRANSISTOR 2SC3661
Q103 8-729-802-80 TRANSISTOR 2SC3661
Q104 8-729-802-80 TRANSISTOR 2SC3661
Q105 8-729-802-80 TRANSISTOR 2SC3661
Q106 8-729-802-80 TRANSISTOR 2SC3661
Q107 8-729-216-22 TRANSISTOR 2SA1162-G
Q108 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q109 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q110 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q111 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q112 8-729-141-75 TRANSISTOR 2SD596DV345
Q113 6-550-185-01 TRANSISTOR RT1P137P-TP-1
Q114 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q115 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q116 8-729-421-22 TRANSISTOR UN2211
Q117 8-729-421-22 TRANSISTOR UN2211
Q118 8-729-903-46 TRANSISTOR 2SB1132-P
Q119 8-729-421-22 TRANSISTOR UN2211
Q120 8-729-903-46 TRANSISTOR 2SB1132-P
Q121 8-729-421-22 TRANSISTOR UN2211
Q122 8-729-903-46 TRANSISTOR 2SB1132-P
Q123 8-729-421-22 TRANSISTOR UN2211
Q124 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q125 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q151 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q152 8-729-802-80 TRANSISTOR 2SC3661
Q153 8-729-802-80 TRANSISTOR 2SC3661
Q154 8-729-802-80 TRANSISTOR 2SC3661
Q155 8-729-802-80 TRANSISTOR 2SC3661
Q166 8-729-802-80 TRANSISTOR 2SC3661
Q175 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 8-729-027-43 TRANSISTOR DTC114EKA-T146 (E2, E3, E51)
Q501 6-550-185-01 TRANSISTOR RT1P137P-TP-1
Q502 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q505 8-729-424-12 TRANSISTOR UN2112
Q506 8-729-421-22 TRANSISTOR UN2211
Q507 8-729-424-12 TRANSISTOR UN2112
Q508 8-729-421-22 TRANSISTOR UN2211
Q509 8-729-424-12 TRANSISTOR UN2112
Q510 8-729-421-22 TRANSISTOR UN2211
Q514 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q515 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q520 8-729-802-80 TRANSISTOR 2SC3661
Q521 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q523 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q524 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q526 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q527 8-729-027-43 TRANSISTOR DTC114EKA-T146
