70
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN PAMOTOR (TB)MOTOR (LD)
R575 1-216-845-11 METAL CHIP 100K 5% 1/10W
R578 1-216-821-11 METAL CHIP 1K 5% 1/10W
R579 1-216-839-11 METAL CHIP 33K 5% 1/10W
R580 1-216-864-11 SHORT CHIP 0
R584 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R585 1-216-833-11 METAL CHIP 10K 5% 1/10W
R586 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R587 1-216-833-11 METAL CHIP 10K 5% 1/10W
R588 1-216-837-11 METAL CHIP 22K 5% 1/10W
R589 1-216-845-11 METAL CHIP 100K 5% 1/10W
R590 1-216-833-11 METAL CHIP 10K 5% 1/10W
R591 1-216-833-11 METAL CHIP 10K 5% 1/10W
R592 1-216-845-11 METAL CHIP 100K 5% 1/10W
R593 1-216-845-11 METAL CHIP 100K 5% 1/10W
R594 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T101 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X401 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
******************************************************
1-687-133-12 MOTOR (LD) BOARD
******************************************************
1-687-134-12 MOTOR (TB) BOARD
****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
******************************************************
A-1055-241-A PA BOARD, COMPLETE (GN660: E3)
A-1055-312-A PA BOARD, COMPLETE (GN770: E3/GX9000)
A-4750-963-A PA BOARD, COMPLETE
(GN660: E2, E51, MX, AR)
A-4750-994-A PA BOARD, COMPLETE (GN770: E2, E51, MX)
A-4753-166-A PA BOARD, COMPLETE (GN770:AUS)
******************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C600 1-126-963-11 ELECT 4.7uF 20% 50V
C601 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C602 1-104-658-91 ELECT 100uF 20% 10V
C604 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C605 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-126-965-91 ELECT 22uF 20% 50V
C609 1-128-560-11 ELECT 22uF 20% 100V
C610 1-128-560-11 ELECT 22uF 20% 100V
C616 1-136-495-11 FILM 0.068uF 5% 50V
C617 1-136-495-11 FILM 0.068uF 5% 50V
C618 1-128-582-11 ELECT 10uF 20% 100V
C619 1-128-582-11 ELECT 10uF 20% 100V
C634 1-104-665-11 ELECT 100uF 20% 25V
C635 1-104-665-11 ELECT 100uF 20% 25V
C636 1-107-721-11 ELECT 4.7uF 20% 100V
C637 1-107-721-11 ELECT 4.7uF 20% 100V
C648 1-104-658-91 ELECT 100uF 20% 10V
C649 1-126-964-11 ELECT 10uF 20% 50V
C650 1-126-963-11 ELECT 4.7uF 20% 50V
C651 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C652 1-104-658-91 ELECT 100uF 20% 10V
C654 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C655 1-126-964-11 ELECT 10uF 20% 50V
C656 1-127-815-11 ELECT 3300uF 20% 100V
C657 1-130-777-00 MYLAR 0.1uF 5% 100V
C658 1-127-811-11 ELECT 3300uF 20% 50V
C659 1-136-497-81 FILM 0.1uF 5% 50V
C660 1-131-992-91 CERAMIC CHIP 100000PF 35V
C662 1-126-964-11 ELECT 10uF 20% 50V
C663 1-126-968-11 ELECT 100uF 20% 50V
C666 1-136-495-11 FILM 0.068uF 5% 50V
C667 1-136-495-11 FILM 0.068uF 5% 50V
C676 1-127-815-11 ELECT 3300uF 20% 100V
C677 1-130-777-00 MYLAR 0.1uF 5% 100V
C678 1-127-811-11 ELECT 3300uF 20% 50V
C679 1-136-497-81 FILM 0.1uF 5% 50V
C683 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C684 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(GN770/GX9000)
C693 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C694 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(GN770/GX9000)
C698 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
CN600 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
CN601 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
* CN604 1-564-243-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< DIODE >
D609 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-083-66 DIODE UDZSTE-1718B
D612 8-719-083-66 DIODE UDZSTE-1718B
D620 8-719-988-61 DIODE 1SS355TE-17
D624 8-719-988-61 DIODE 1SS355TE-17
D646 8-719-988-61 DIODE 1SS355TE-17
D654 8-719-988-61 DIODE 1SS355TE-17
D655 8-719-988-61 DIODE 1SS355TE-17
D656 8-719-066-42 DIODE RBV1306
D658 8-719-510-68 DIODE D5SBA204101
D660 8-719-988-61 DIODE 1SS355TE-17
D661 8-719-988-61 DIODE 1SS355TE-17
D664 8-719-083-87 DIODE UDZSTE-1733B
D665 8-719-988-61 DIODE 1SS355TE-17 (GN770/GX9000)
D670 8-719-988-61 DIODE 1SS355TE-17
D699 6-500-522-21 DIODE 10EDB40-TB3
< EARTH TERMINAL >
EP660 1-537-738-21 TERMINAL, GROUND
EP690 1-537-738-21 TERMINAL, GROUND
