HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
PA PANEL
R670 1-216-839-11 METAL CHIP 33K 5% 1/10W
R671 1-216-845-11 METAL CHIP 100K 5% 1/10W
R672 1-249-625-31 CARBON 10 5% 1/2W
R673 1-216-842-11 METAL CHIP 56K 5% 1/10W
R674 1-216-837-11 METAL CHIP 22K 5% 1/10W
R676 1-216-849-11 METAL CHIP 220K 5% 1/10W
R677 1-216-849-11 METAL CHIP 220K 5% 1/10W
R678 1-216-845-11 METAL CHIP 100K 5% 1/10W
R682 1-216-821-11 METAL CHIP 1K 5% 1/10W
R683 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R692 1-216-841-11 METAL CHIP 47K 5% 1/10W
R693 1-216-843-11 METAL CHIP 68K 5% 1/10W
R694 1-216-843-11 METAL CHIP 68K 5% 1/10W
R695 1-216-845-11 METAL CHIP 100K 5% 1/10W
R696 1-216-845-11 METAL CHIP 100K 5% 1/10W
R697 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0R699 1-219-124-11 FUSIBLE 0.68 5% 1/4W
< RELAY >
RY646 1-755-372-11 RELAY
RY665 1-755-372-11 RELAY (GN770/GX9000)
< THERMISTOR >
TH629 1-807-796-11 THERMISTOR
TH630 1-807-796-11 THERMISTOR
< TERMINAL >
TM600 1-537-114-21 TERMINAL BOARD (SPEAKER) (GN660)
TM601 1-816-048-11 TERMINAL BOARD
(FRONT/SURROUND SPEAKER L)
(GN770/GX9000)
TM602 1-816-048-11 TERMINAL BOARD
(FRONT/SURROUND SPEAKER R)
(GN770/GX9000)
************************************************************
A-1056-930-A PANEL BOARD, COMPLETE (MX)
A-4750-973-A PANEL BOARD, COMPLETE (EXCEPT MX)
*******************
4-231-581-01 HOLDER (FL)
< CAPACITOR >
C900 1-126-163-11 ELECT 4.7uF 20% 50V
C901 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C902 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C903 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C906 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C907 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C908 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C909 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C911 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C912 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C913 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C914 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C915 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C917 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C918 1-119-941-91 ELECT 470uF 20% 6.3V
C919 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C920 1-124-589-11 ELECT 47uF 20% 16V
C922 1-124-261-00 ELECT 10uF 20% 50V
C923 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C924 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C925 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C926 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C927 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C928 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C929 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C930 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C931 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C932 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C933 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C934 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C935 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C936 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C937 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C938 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C939 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C940 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C941 1-124-261-00 ELECT 10uF 20% 50V
C942 1-124-261-00 ELECT 10uF 20% 50V
C944 1-124-261-00 ELECT 10uF 20% 50V
C945 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C946 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C947 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C948 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C949 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C950 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C951 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C952 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C953 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C954 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C955 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C956 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C957 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C958 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C959 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C960 1-124-261-00 ELECT 10uF 20% 50V
C961 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C963 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C966 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C967 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C968 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C969 1-126-968-11 ELECT 100uF 20% 50V
C971 1-119-941-91 ELECT 470uF 20% 6.3V
C972 1-119-941-11 ELECT 470uF 20% 6.3V
C980 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C981 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C982 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C983 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C984 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C985 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
