HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D1304 6-501-175-01 DIODE UDZW-TE17-11B (GTR7/GTR8/GTR8B)
D1304 6-501-767-01 DIODE MAZ8120GLLS0 (GTR6/GTR6B)
D1305 6-500-968-21 DIODE 30PRA20FC
D1306 6-501-175-01 DIODE UDZW-TE17-11B (GTR7/GTR8/GTR8B)
D1306 6-501-767-01 DIODE MAZ8120GLLS0 (GTR6/GTR6B)
D1307 6-500-968-21 DIODE 30PRA20FC
D1302 6-501-817-01 DIODE MA2J1110GLS0
D1308 6-501-817-01 DIODE MA2J1110GLS0
D1309 6-500-334-01 DIODE MC2836-T112-1
D1310 6-501-754-01 DIODE MAZ8091G0LS0
D1313 8-719-073-32 DIODE D25XB60
D1314 8-719-073-32 DIODE D25XB60
D1315 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC1300 6-713-774-01 IC STK412-770-E (GTR6/GTR6B)
IC1301 6-713-787-01 IC STK412-750-E (GTR7/GTR8/GTR8B)
< JACK >
JK1300 1-820-067-11 TERMINAL BOARD (SURROUND SPEAKER)
JK1301 1-820-067-11 TERMINAL BOARD (FRONT SPEAKER)
< JUMPER RESISTOR >
JR1300 1-216-864-11 SHORT CHIP 0 (GTR7/GTR8/GTR8B)
< TRANSISTOR >
Q1300 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
(GTR7/GTR8/GTR8B)
Q1315 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q1316 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1303 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1305 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q1306 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1307 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1308 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1309 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1310 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1301 1-216-821-11 METAL CHIP 1K 5% 1/10W
(GTR7/GTR8/GTR8B)
R1307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1316 1-245-605-55 FUSIBLE 100 5% 1/4W
R1318 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1326 1-216-864-11 SHORT CHIP 0
R1327 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GTR6/GTR6B)
R1327 1-216-838-11 METAL CHIP 27K 5% 1/10W
(GTR7/GTR8/GTR8B)
R1332 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1333 1-216-818-11 METAL CHIP 560 5% 1/10W
(GTR6/GTR6B)
R1333 1-216-819-11 METAL CHIP 680 5% 1/10W
(GTR8/GTR8B)
R1333 1-216-820-11 METAL CHIP 820 5% 1/10W
(GTR7)
R1334 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1335 1-216-818-11 METAL CHIP 560 5% 1/10W
(GTR6/GTR6B)
R1335 1-216-819-11 METAL CHIP 680 5% 1/10W
(GTR8/GTR8B)
R1335 1-216-820-11 METAL CHIP 820 5% 1/10W
(GTR7)
R1336 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GTR6/GTR6B)
R1336 1-216-840-11 METAL CHIP 39K 5% 1/10W
(GTR7/GTR8/GTR8B)
R1337 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1338 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1339 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GTR6/GTR6B)
R1339 1-216-840-11 METAL CHIP 39K 5% 1/10W
(GTR7/GTR8/GTR8B)
R1341 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1342 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1347 1-216-840-11 METAL CHIP 39K 5% 1/10W
R1374 1-234-798-11 ENCAPSULATED COMPONENT
R1375 1-234-798-11 ENCAPSULATED COMPONENT
R1380 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1381 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1394 1-246-024-21 METAL CHIP 150 5% 1/2W
(GTR7/GTR8/GTR8B)
R1306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1313 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1314 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1315 1-217-637-55 FUSIBLE 1 5% 1/4W
R1317 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1319 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1320 1-245-711-31 CARBON 10 5% 1/2W
R1321 1-245-711-31 CARBON 10 5% 1/2W
R1323 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1328 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1329 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1331 1-245-605-55 FUSIBLE 100 5% 1/4W
R1340 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1343 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1344 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1345 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1365 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1367 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1370 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1372 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1395 1-246-024-21 METAL CHIP 150 5% 1/2W
R1396 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1397 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
RY1300 1-755-307-21 RELAY (GTR7/GTR8/GTR8B)
RY1300 1-755-308-21 RELAY (GTR7/GTR8/GTR8B)
RY1301 1-755-307-21 RELAY
< THERMISTOR >
TH1300 1-807-796-11 THERMISTOR
TH1301 1-804-045-11 THERMISTOR
************************************************************
