Sony HCD-GTR7 - Page 78

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
78
HCD-GTR6/GTR6B/GTR7/GTR8/GTR8B
LED
HEADPHONE BOARD
*****************
< CAPACITOR >
C1060 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1061 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1062 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D1050 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB1001 1-469-116-21 FERRITE, EMI (SMD) (1608)
FB1002 1-469-116-21 FERRITE, EMI (SMD) (1608)
FB1003 1-469-116-21 FERRITE, EMI (SMD) (1608)
< JACK >
J1005 1-794-702-11 JACK, HEADPHONE (PHONE)
************************************************************
HUB BOARD
**********
< CAPACITOR >
C1500 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1501 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1502 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1503 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1504 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1507 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1508 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1510 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1511 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1512 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1514 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1515 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1517 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1519 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1520 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1522 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1523 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1524 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1525 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1526 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN1501 1-774-729-21 PIN, CONNECTOR (PC BOARD) 10P
CN1503 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN1554 1-820-121-41 CONNECTOR, FFC/FPC 23P
CN1555 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN1556 1-785-466-41 CONNECTOR, FFC/FPC 7P
< FERRITE BEAD >
FB1500 1-216-295-91 SHORT CHIP 0
FB1501 1-216-295-91 SHORT CHIP 0
FB1502 1-216-295-91 SHORT CHIP 0
FB1503 1-216-295-91 SHORT CHIP 0
< IC >
IC1500 8-759-338-95 IC NJM2903V (TE2)
IC1501 6-714-034-01 IC USB2512A-AEZG
< RESISTOR >
R1500 1-216-809-11 METAL CHIP 100 5% 1/10W
R1501 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1502 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1503 1-216-815-11 METAL CHIP 330 5% 1/10W
R1504 1-218-446-11 METAL CHIP 1 5% 1/10W
R1505 1-218-446-11 METAL CHIP 1 5% 1/10W
R1506 1-218-446-11 METAL CHIP 1 5% 1/10W
R1507 1-218-446-11 METAL CHIP 1 5% 1/10W
R1508 1-218-446-11 METAL CHIP 1 5% 1/10W
R1509 1-218-446-11 METAL CHIP 1 5% 1/10W
R1510 1-218-446-11 METAL CHIP 1 5% 1/10W
R1511 1-218-446-11 METAL CHIP 1 5% 1/10W
R1512 1-218-446-11 METAL CHIP 1 5% 1/10W
R1513 1-218-446-11 METAL CHIP 1 5% 1/10W
R1514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1515 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1516 1-216-815-11 METAL CHIP 330 5% 1/10W
R1517 1-218-446-11 METAL CHIP 1 5% 1/10W
R1518 1-218-446-11 METAL CHIP 1 5% 1/10W
R1519 1-218-446-11 METAL CHIP 1 5% 1/10W
R1520 1-218-446-11 METAL CHIP 1 5% 1/10W
R1521 1-218-446-11 METAL CHIP 1 5% 1/10W
R1522 1-218-446-11 METAL CHIP 1 5% 1/10W
R1523 1-218-446-11 METAL CHIP 1 5% 1/10W
R1524 1-218-446-11 METAL CHIP 1 5% 1/10W
R1525 1-218-446-11 METAL CHIP 1 5% 1/10W
R1526 1-218-446-11 METAL CHIP 1 5% 1/10W
R1527 1-216-809-11 METAL CHIP 100 5% 1/10W
R1528 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1530 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1533 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1535 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R1537 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1538 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1540 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1541 1-216-809-11 METAL CHIP 100 5% 1/10W
R1543 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1544 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1546 1-216-809-11 METAL CHIP 100 5% 1/10W
R1547 1-216-834-11 METAL CHIP 12K 5% 1/10W
R1549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1550 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X1500 1-760-613-21 VIBRATOR, CRYSTAL (24 MHZ)
************************************************************
LED (GTH) BOARD
***************
< RESISTOR >
R016 1-216-818-11 METAL CHIP 560 5% 1/10W
R017 1-216-818-11 METAL CHIP 560 5% 1/10W
R022 1-216-818-11 METAL CHIP 560 5% 1/10W
R023 1-216-818-11 METAL CHIP 560 5% 1/10W
************************************************************
HUBHEADPHONE
