111
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D782 8-719-080-67 LED SELU6714C-TP6 (LCD BACK LIGHT)
D783 8-719-080-67 LED SELU6714C-TP6 (LCD BACK LIGHT)
D784 8-719-080-67 LED SELU6714C-TP6 (LCD BACK LIGHT)
D785 8-719-080-67 LED SELU6714C-TP6 (LCD BACK LIGHT)
D786 8-719-080-67 LED SELU6714C-TP6 (LCD BACK LIGHT)
< IC >
IC701 8-759-459-85 IC NJL63H400A
IC702 8-759-587-81 IC NJU3716M-TE2
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR UN4211-TA
Q702 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q703 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q704 8-729-900-80 TRANSISTOR UN4211-TA
< RESISTOR >
R701 1-247-807-31 CARBON 100 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-247-807-31 CARBON 100 5% 1/4W
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-249-417-11 CARBON 1K 5% 1/4W
R708 1-249-429-11 CARBON 10K 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R712 1-249-417-11 CARBON 1K 5% 1/4W
R713 1-249-431-11 CARBON 15K 5% 1/4W
R717 1-249-417-11 CARBON 1K 5% 1/4W
R718 1-247-807-31 CARBON 100 5% 1/4W
R719 1-249-441-11 CARBON 100K 5% 1/4W
R720 1-249-413-11 CARBON 470 5% 1/4W
R721 1-249-413-11 CARBON 470 5% 1/4W
R722 1-249-409-11 CARBON 220 5% 1/4W
R723 1-249-415-11 CARBON 680 5% 1/4W
R724 1-249-415-11 CARBON 680 5% 1/4W
R725 1-249-407-11 CARBON 150 5% 1/4W
R726 1-249-409-11 CARBON 220 5% 1/4W
R727 1-249-417-11 CARBON 1K 5% 1/4W
R728 1-249-417-11 CARBON 1K 5% 1/4W
R729 1-249-407-11 CARBON 150 5% 1/4W
R730 1-249-413-11 CARBON 470 5% 1/4W
R731 1-249-419-11 CARBON 1.5K 5% 1/4W
R732 1-249-419-11 CARBON 1.5K 5% 1/4W
R733 1-249-419-11 CARBON 1.5K 5% 1/4W
R734 1-249-407-11 CARBON 150 5% 1/4W
R735 1-249-411-11 CARBON 330 5% 1/4W
R736 1-249-421-11 CARBON 2.2K 5% 1/4W
R737 1-249-409-11 CARBON 220 5% 1/4W
R738 1-247-843-11 CARBON 3.3K 5% 1/4W
R739 1-249-411-11 CARBON 330 5% 1/4W
R740 1-249-425-11 CARBON 4.7K 5% 1/4W
R741 1-249-409-11 CARBON 220 5% 1/4W
R742 1-249-427-11 CARBON 6.8K 5% 1/4W
R743 1-249-411-11 CARBON 330 5% 1/4W
R744 1-249-429-11 CARBON 10K 5% 1/4W
R745 1-249-409-11 CARBON 220 5% 1/4W
R746 1-249-431-11 CARBON 15K 5% 1/4W
R747 1-249-411-11 CARBON 330 5% 1/4W
R748 1-249-411-11 CARBON 330 5% 1/4W
R749 1-249-433-11 CARBON 22K 5% 1/4W
R750 1-249-435-11 CARBON 33K 5% 1/4W
R751 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-249-411-11 CARBON 330 5% 1/4W
R757 1-249-411-11 CARBON 330 5% 1/4W
R764 1-249-393-11 CARBON 10 5% 1/4W
R765 1-249-417-11 CARBON 1K 5% 1/4W
R766 1-249-429-11 CARBON 10K 5% 1/4W
R767 1-247-807-31 CARBON 100 5% 1/4W
R769 1-249-403-11 CARBON 68 5% 1/4W
R770 1-249-387-11 CARBON 3.3 5% 1/4W
R771 1-249-391-11 CARBON 6.8 5% 1/4W
R772 1-249-391-11 CARBON 6.8 5% 1/4W
R773 1-249-391-11 CARBON 6.8 5% 1/4W
R774 1-249-391-11 CARBON 6.8 5% 1/4W
R775 1-249-391-11 CARBON 6.8 5% 1/4W
R776 1-249-391-11 CARBON 6.8 5% 1/4W
< SWITCH >
S701 1-476-349-11 ENCODER, ROTARY (VOLUME)
S702 1-762-875-21 SWITCH, KEYBOARD (I/1)
S703 1-762-875-21 SWITCH, KEYBOARD (CDN X)
S704 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S705 1-762-875-21 SWITCH, KEYBOARD (MDN X)
S706 1-762-875-21 SWITCH, KEYBOARD (MDZ)
S707 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S708 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
S709 1-762-875-21 SWITCH, KEYBOARD (x)
S710 1-762-875-21 SWITCH, KEYBOARD (SYNC MODE)
S712 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HIGH SPEED)
S713 1-762-875-21 SWITCH, KEYBOARD
(CD SYNC NORM SPEED)
S714 1-762-875-21 SWITCH, KEYBOARD (REC/REC IT)
S715 1-762-875-21 SWITCH, KEYBOARD (REC MODE)
S716 1-762-875-21 SWITCH, KEYBOARD
(REPEAT STEREO/MONO)
S717 1-762-875-21 SWITCH, KEYBOARD (Z (CD3))
S718 1-762-875-21 SWITCH, KEYBOARD (CD3)
S719 1-762-875-21 SWITCH, KEYBOARD (Z (CD2))
S720 1-762-875-21 SWITCH, KEYBOARD (CD2)
S721 1-762-875-21 SWITCH, KEYBOARD (Z (CD1))
S722 1-762-875-21 SWITCH, KEYBOARD (CD1)
**************************************************************
POWER BOARD
*************
1-533-293-11 FUSE HOLDER (JE)
PANEL POWER
