112
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CAPACITOR >
C901 1-126-916-11 ELECT 1000uF 20% 6.3V
C902 1-126-965-11 ELECT 22uF 20% 35V
C904 1-113-342-11 CERAMIC 0.1uF 50V
C905 1-126-937-11 ELECT 4700uF 20% 16V
C908 1-136-165-00 MYLAR 0.1uF 5% 50V
0C911 1-113-925-11 CERAMIC 0.01uF 20% 250V
C925 1-104-665-11 ELECT 100uF 20% 10V
< CONNECTOR >
* CN901 1-564-519-11 PLUG, CONNECTOR 4P
* CN903 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN905 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D932 8-719-200-82 DIODE 11ES2-TA2B
D940 8-719-911-19 DIODE 1SS133T-72
D941 8-719-911-19 DIODE 1SS133T-72
D942 8-719-200-82 DIODE 11ES2-TA2B
D943 8-719-200-82 DIODE 11ES2-TA2B
D944 8-719-200-82 DIODE 11ES2-TA2B
D945 8-719-200-82 DIODE 11ES2-TA2B
D951 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0F903 1-532-502-31 FUSE (T1.25AL/250V) (JE)
< IC >
IC901 8-759-450-47 IC BA05T
< TRANSISTOR >
Q901 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R901 1-247-843-11 CARBON 3.3K 5% 1/4W
R902 1-249-413-11 CARBON 470 5% 1/4W
0R903 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
R906 1-249-413-11 CARBON 470 5% 1/4W
R907 1-249-417-11 CARBON 1K 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY961 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-937-11 TRANSFORMER, POWER (HK, KR)
0T901 1-435-938-11 TRANSFORMER, POWER (JE)
0T902 1-435-939-11 TRANSFORMER, POWER (HK, KR)
0T902 1-435-940-11 TRANSFORMER, POWER (JE)
0T906 1-424-485-11 FILTER, LINE
**************************************************************
REG BOARD
**********
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C800 1-126-960-11 ELECT 1uF 20% 50V
C801 1-126-960-11 ELECT 1uF 20% 50V
C903 1-126-943-11 ELECT 2200uF 20% 25V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C907 1-115-364-11 ELECT 22000uF 20% 16V
C909 1-130-495-00 MYLAR 0.1uF 5% 50V
C910 1-130-495-00 MYLAR 0.1uF 5% 50V
C914 1-130-495-00 MYLAR 0.1uF 5% 50V
C915 1-104-665-11 ELECT 100uF 20% 10V
C916 1-104-665-11 ELECT 100uF 20% 10V
C919 1-104-665-11 ELECT 100uF 20% 10V
C920 1-113-342-11 CERAMIC 0.1uF 50V
C921 1-130-495-00 MYLAR 0.1uF 5% 50V
C923 1-104-665-11 ELECT 100uF 20% 10V
C924 1-130-495-00 MYLAR 0.1uF 5% 50V
C926 1-126-935-11 ELECT 470uF 20% 10V
C927 1-130-495-00 MYLAR 0.1uF 5% 50V
C928 1-104-665-11 ELECT 100uF 20% 10V
C929 1-104-665-11 ELECT 100uF 20% 10V
C930 1-130-495-00 MYLAR 0.1uF 5% 50V
C931 1-104-665-11 ELECT 100uF 20% 10V
< CONNECTOR >
* CN805 1-770-729-11 CONNECTOR, BOARD TO BOARD 10P
* CN904 1-564-519-11 PLUG, CONNECTOR 4P
* CN907 1-564-523-11 PLUG, CONNECTOR 8P
CN908 1-564-521-11 PLUG, CONNECTOR 6P
< DIODE >
D800 8-719-110-06 DIODE RD8.2ES-T2B1
D830 8-719-083-06 DIODE MTZJ-T-72-10A
D946 8-719-200-82 DIODE 11ES2-TA2B
D947 8-719-200-82 DIODE 11ES2-TA2B
D948 8-719-210-21 DIODE 11EQS04-TA2B
D949 8-719-210-21 DIODE 11EQS04-TA2B
D956 8-719-200-82 DIODE 11ES2-TA2B
D958 8-719-200-82 DIODE 11ES2-TA2B
D959 8-719-200-82 DIODE 11ES2-TA2B
D960 8-719-200-82 DIODE 11ES2-TA2B
D961 8-719-200-82 DIODE 11ES2-TA2B
D963 8-719-200-82 DIODE 11ES2-TA2B
D964 8-719-200-82 DIODE 11ES2-TA2B
D965 8-719-200-82 DIODE 11ES2-TA2B
D971 8-719-028-23 DIODE D3SBA20-4101
< FUSE >
0F803 1-532-504-31 FUSE (T4AL/250V)
< IC >
IC911 8-759-605-00 IC M5F78M07L
IC912 8-759-394-35 IC BA12T
IC916 8-759-158-62 IC TA78057S
IC917 8-759-701-75 IC NJM7805FA
IC919 8-759-445-59 IC BA033T
POWER REG
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
