113
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TRANSISTOR >
Q800 8-729-209-15 TRANSISTOR 2SD2012
Q801 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
R830 1-249-411-11 CARBON 330 5% 1/4W
R831 1-249-409-11 CARBON 220 5% 1/4W
0R904 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
0R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
< THERMISTOR (POSITIVE) >
THP501 1-803-350-21 THERMISTOR, POSITIVE
THP503 1-803-350-21 THERMISTOR, POSITIVE
**************************************************************
RELAY BOARD
************
< CONNECTOR >
CN791 1-784-833-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN792 1-784-833-21 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
**************************************************************
SELECTOR BOARD (JE)
***************
< CONNECTOR >
* CN993 1-580-445-11 PIN, CONNECTOR 3P
* CN994 1-580-445-11 PIN, CONNECTOR 3P
< SWITCH >
0S991 1-554-752-11 SELECTOR, POWER VOLTAGE
(VOLTAGE SELECTOR)
**************************************************************
TRAY SENSOR BOARD
******************
< CAPACITOR >
C731 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO SENSOR >
IC731 8-749-081-01 PHOTO SENSOR DG-264
IC732 8-749-081-01 PHOTO SENSOR DG-264
IC733 8-749-081-01 PHOTO SENSOR DG-264
< RESISTOR >
R731 1-247-876-11 CARBON 75K 5% 1/4W
R732 1-249-408-11 CARBON 180 5% 1/4W
R733 1-247-876-11 CARBON 75K 5% 1/4W
R734 1-249-408-11 CARBON 180 5% 1/4W
R735 1-247-876-11 CARBON 75K 5% 1/4W
R736 1-249-408-11 CARBON 180 5% 1/4W
**************************************************************
MISCELLANEOUS
**************
4 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)
6 1-693-472-21 TUNER (JE)
6 1-693-473-41 TUNER (HK, KR)
65 1-757-087-11 WIRE (FLAT TYPE) (23 CORE)
104 1-757-548-11 WIRE (FLAT TYPE) (31 CORE)
105 1-757-086-11 WIRE (FLAT TYPE) (21 CORE)
106 1-757-084-11 WIRE (FLAT TYPE) (27 CORE)
107 1-757-085-11 WIRE (FLAT TYPE) (17 CORE)
0110 1-575-651-21 CORD, POWER (HK, JE)
0110 1-769-079-11 CORD, POWER (KR)
357 1-678-514-11 FLEXIBLE BOARD
0358 A-4672-976-A OPTICAL PICK-UP KMS-262A/J1N
0574 A-4677-295-A BASE UNIT (BU-21BD53)
577 1-757-124-11 WIRE (FLAT TYPE) (21 CORE)
HR901 1-500-670-12 HEAD, OVER LIGHT
LCD600 1-804-158-11 DISPLAY PANEL, LIQUID CRYSTAL
M101 A-4735-029-A MOTOR ASSY, SPINDLE (for MD)
M102 A-4672-900-A MOTOR ASSY, SLED (for MD)
M103 A-4672-975-A MOTOR ASSY, LOADING (for MD)
M721 1-541-632-11 MOTOR, DC (LOADING) (for CD)
M801 1-763-632-11 FAN, DC
S102 1-771-957-11 SWITCH, PUSH (2 KEY)
(REFLECT RATE DETECT, PROTECT DETECT)
0T901 1-435-937-11 TRANSFORMER, POWER (HK, KR)
0T901 1-435-938-11 TRANSFORMER, POWER (JE)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-204-19 SCREW +KTP 2X6 TYPE2 NON-SLIT
#2 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#6 7-685-871-01 SCREW +BVTT 3X6 (S)
#7 7-685-651-79 SCREW +BVTT 3X20
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-569-008-21 ADAPTOR, CONVERSION 2P (JE)
1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
REG RELAY SELECTOR TRAY SENSOR
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
