Sony HCD-PX5 - Page 22

22
1 two screws
(BVTT3
× 6)
3 Remove the shield case (upper),
in the direction of arrow
A .
4 wire (flat type)
(17 core) (CN1004)
4 wire (flat type)
(27 core) (CN1003
)
5 connector (CN1006)
6 screw (BVTT3 × 6)
2 lug
A
9
1
two screws
(BVTT3
× 6)
7 MD DIGITAL board
8 four step screws
(BVTTWH M3)
q; three insulators
q; insulator
qa MD mechanism deck
(MDM-7X2A)
4 four screws (BVTP2.6 × 8)
4 six screws
(BVTP2.6
× 8)
4 three screws (BVTP2.6 × 8)
7 bracket (JOG)
6 screw
(BVTP2.6
× 8)
6 screw
(BVTP2.6
× 8
)
8 two screws (BVTP2.6 × 8)
0 three screws
(BVTP2.6
× 10)
5 PANEL board
1 knob (VOLUME) assy
2 nut
3 ring (VOL)
9 JOG board
qa JACK board
MD DIGITAL BOARD, MD MECHANISM DECK (MDM-7X2A)
PANEL BOARD
