31
IN OUT SW BOARD
MOTOR ASSY (M721), MOTOR BOARD
1
connector (CN704
)
2
two screws (BTTP M2.6)
3
IN OUT SW board
4
two screws (BTTP M2.6)
2
connector (CN702)
7
motor assy (M721)
5
motor board
6
1
belt
3
Remove two solders.
motor board bottom view
