STOCKER ASSY, TRAY (SUB)
DISC SENSOR BOARD
2
Slide the slider (BU.L),
slider (BU.R) in the direction of
arrow
A
at the full.
A
A
3
stocker assy, tray (sub)
1
screw (M2.6)
1
screw (M2.6)
4
DISC SENSOR board
2
CD base unit assy
3
two screws (BTTP M2.6)
