Sony HCD-RX77 - Page 76

– 104 –
MAIN MOTOR (SLIDE) MOTOR (TURN)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R546 1-247-843-11 CARBON 3.3K 5% 1/4W
R547 1-247-807-31 CARBON 100 5% 1/4W
R548 1-247-807-31 CARBON 100 5% 1/4W
R549 1-247-807-31 CARBON 100 5% 1/4W
R550 1-247-807-31 CARBON 100 5% 1/4W
R551 1-247-807-31 CARBON 100 5% 1/4W
R552 1-247-807-31 CARBON 100 5% 1/4W
R553 1-249-429-11 CARBON 10K 5% 1/4W
R554 1-247-807-31 CARBON 100 5% 1/4W
R555 1-249-429-11 CARBON 10K 5% 1/4W
R556 1-247-807-31 CARBON 100 5% 1/4W
R557 1-249-429-11 CARBON 10K 5% 1/4W
R558 1-247-807-31 CARBON 100 5% 1/4W
R559 1-249-429-11 CARBON 10K 5% 1/4W
R561 1-247-807-31 CARBON 100 5% 1/4W
R562 1-247-807-31 CARBON 100 5% 1/4W
R563 1-247-807-31 CARBON 100 5% 1/4W
R564 1-247-807-31 CARBON 100 5% 1/4W
R565 1-247-807-31 CARBON 100 5% 1/4W
R566 1-247-807-31 CARBON 100 5% 1/4W
R567 1-247-807-31 CARBON 100 5% 1/4W
R571 1-249-421-11 CARBON 2.2K 5% 1/4W
R572 1-249-441-11 CARBON 100K 5% 1/4W
R576 1-249-429-11 CARBON 10K 5% 1/4W
R577 1-249-417-11 CARBON 1K 5% 1/4W
R901 1-247-843-11 CARBON 3.3K 5% 1/4W
R902 1-249-415-11 CARBON 680 5% 1/4W
R903 1-249-419-11 CARBON 1.5K 5% 1/4W
R904 1-249-414-11 CARBON 560 5% 1/4W
R905 1-249-425-11 CARBON 4.7K 5% 1/4W
R906 1-247-843-11 CARBON 3.3K 5% 1/4W
R907 1-249-415-11 CARBON 680 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
R909 1-249-430-11 CARBON 12K 5% 1/4W
R911 1-249-409-11 CARBON 220 5% 1/4W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-249-425-11 CARBON 4.7K 5% 1/4W
R914 1-249-409-11 CARBON 220 5% 1/4W
R915 1-249-409-11 CARBON 220 5% 1/4W
R920 1-249-383-11 CARBON 1.5 5% 1/6W
R921 1-249-383-11 CARBON 1.5 5% 1/6W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< RELAY >
RY401 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SPEAKER)
TM402 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SURROUND SPEAKER) (CND)
< VIBRATOR >
X501 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X502 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
