Sony HCD-RX77 - Page 77

– 105 –
PANEL
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4403-990-A PANEL BOARD, COMPLETE (EE, CIS)
* A-4407-013-A PANEL BOARD, COMPLETE
(EXCEPT AEP, UK, G, EE, CIS, EA3)
* A-4407-015-A PANEL BOARD, COMPLETE (EA3)
* A-4407-998-A PANEL BOARD, COMPLETE (AEP, UK,G)
**********************
* 4-949-935-21 CUSHION (FL)
* 4-996-724-01 HOLDER, FL TUBE
< CAPACITOR >
C601 1-164-159-11 CERAMIC 0.1uF 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-124-589-11 ELECT 47uF 20% 16V
C604 1-126-163-11 ELECT 4.7uF 20% 50V
C605 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-162-282-31 CERAMIC 100PF 10% 50V
C611 1-162-282-31 CERAMIC 100PF 10% 50V
C612 1-162-282-31 CERAMIC 100PF 10% 50V
C613 1-162-282-31 CERAMIC 100PF 10% 50V
C614 1-162-282-31 CERAMIC 100PF 10% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-162-282-31 CERAMIC 100PF 10% 50V
C617 1-162-282-31 CERAMIC 100PF 10% 50V
C618 1-162-282-31 CERAMIC 100PF 10% 50V
C619 1-162-282-31 CERAMIC 100PF 10% 50V
C620 1-162-282-31 CERAMIC 100PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-162-306-11 CERAMIC 0.01uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
C631 1-126-157-11 ELECT 10uF 20% 16V
C632 1-126-157-11 ELECT 10uF 20% 16V
C633 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C634 1-126-157-11 ELECT 10uF 20% 16V
C635 1-126-163-11 ELECT 4.7uF 20% 50V
C648 1-162-306-11 CERAMIC 0.01uF 20% 16V
C649 1-124-589-11 ELECT 47uF 20% 16V
C749 1-164-159-11 CERAMIC 0.1uF 50V
C752 1-164-159-11 CERAMIC 0.1uF 50V
C753 1-162-290-31 CERAMIC 470PF 10% 50V
C754 1-162-306-11 CERAMIC 0.01uF 20% 16V
C755 1-126-961-11 ELECT 2.2uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-215-31 CERAMIC 47PF 5% 50V
C758 1-126-964-11 ELECT 10uF 20% 50V
C759 1-126-956-91 ELECT 0.1uF 20% 50V
C760 1-162-215-31 CERAMIC 47PF 5% 50V
C761 1-162-282-31 CERAMIC 100PF 10% 50V
C762 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-126-964-11 ELECT 10uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
(EA3)
C766 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(EA3)
C767 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EA3)
C768 1-136-495-11 FILM 0.068uF 5% 50V
(EA3)
C769 1-126-957-11 ELECT 0.22uF 20% 50V
(EA3)
C770 1-126-957-11 ELECT 0.22uF 20% 50V
(EA3)
C771 1-126-967-11 ELECT 47uF 20% 10V
(EA3)
C772 1-164-159-11 CERAMIC 0.1uF 50V
(EA3)
C773 1-126-967-11 ELECT 47uF 20% 10V
(EA3)
C774 1-136-495-11 FILM 0.068uF 5% 50V
(EA3)
C775 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(EA3)
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EA3)
C777 1-136-167-00 FILM 0.15uF 5% 50V
(EA3)
C778 1-126-960-11 ELECT 1uF 20% 50V
(EA3)
C779 1-161-494-00 CERAMIC 0.022uF 25V
(EA3)
C780 1-126-961-11 ELECT 2.2uF 20% 50V
(EA3)
< CONNECTOR >
* CN601 1-568-856-11 SOCKET, CONNECTOR 13P
< DIODE >
D602 8-719-986-73 DIODE RB441Q
D610 8-719-063-93 LED SLR325VC-N-T32 (ENTER/NEXT)
D612 8-719-057-97 LED SEL5923A-TP15 (GROOVE)
D613 8-719-063-93 LED SLR325VC-N-T32 (JOG)
D614 8-719-064-65 LED SELU5723C-TP15 (DJ MIX)
D615 8-719-064-65 LED SELU5723C-TP15 (DJ MIX)
D616 8-719-063-93 LED SLR325VC-N-T32 (NON-STOP)
D617 8-719-057-97 LED SEL5923A-TP15 (+, ))
D618 8-719-057-97 LED SEL5923A-TP15 (–, 0)
D620 8-719-063-93 LED SLR325VC-N-T32 (EFFECT)
(GRX7/GRX7J/RX77: CND)
D621 8-719-056-13 LED SML79423C-TP15 (CD, ^)
D622 8-719-058-03 LED SEL5423E-TP15 (TAPE B, ()
D623 8-719-058-03 LED SEL5423E-TP15 (TAPE B, 9)
D624 8-719-058-03 LED SEL5423E-TP15 (TAPE A, ()
D625 8-719-058-03 LED SEL5423E-TP15 (TAPE A, 9)
D651 8-719-063-93 LED SLR325VC-N-T32 (r REC)
D652 8-719-057-97 LED SEL5923A-TP15 (P PAUSE)
D751 8-719-024-99 DIODE 11ES2-NTA2B (EA3)
D752 8-719-024-99 DIODE 11ES2-NTA2B (EA3)
D753 8-719-024-99 DIODE 11ES2-NTA2B (EA3)
