HCD-SR4W
Pin No. Pin Name I/O Description
117 to 120 WAD4 to WAD7 I External A/D data input terminal for PSP physical disc mark detection Not used
121 VDCB2 Power supply terminal (+2.5V) (for core)
122 WRFD I Not used
123 WCK I
Operation clock signal input for PSP physical disc mark detection from the DVD
decoder
124, 125 WAVDD0, WAVDD1 A/D power supply terminal (+2.5V) (for PSP physical disc mark detection)
126 WARFI I
Analog RF signal input for PSP physical disc mark detection from the DVD/CD
RF amplifier
127 WAVRB I A/D bottom reference terminal for PSP physical disc mark detection
128, 129 WAVSS0, WAVSS1 A/D ground terminal (for PSP physical disc mark detection)
130 VSIO Ground terminal (for I/O)
131 to 134 DQ7 to DQ4 I/O Two-way data bus with the SD-RAM
135 VDIOA2 Power supply terminal (+3.3V) (for I/O)
136 to 139 DQ3 to DQ0 I/O Two-way data bus with the SD-RAM
140 VSIOA3 Ground terminal (for I/O)
141 DCLK O Clock signal output to the SD-RAM
142 DCKE O Clock enable signal output to the SD-RAM
143 XWE O Write enable signal output to the SD-RAM
144 XCAS O Column address strobe signal output to the SD-RAM
145 XRAS O Row address strobe signal output to the SD-RAM
146 VDIOA3 Power supply terminal (+3.3V) (for I/O)
147 NC O Not used
148, 149 A11, A10 O Address signal output to the SD-RAM
150 VSCA3 Ground terminal (for core)
151, 152 A9, A8 O Address signal output to the SD-RAM
153 VDCA3 Power supply terminal (+2.5V) (for core)
154 to 157 A7 to A4 O Address signal output to the SD-RAM
158 VSIOA4 Ground terminal (for I/O)
159 to 162 A3 to A0 O Address signal output to the SD-RAM
163 VDIOA4 Power supply terminal (+3.3V) (for I/O)
164 XSRQ O Serial data request signal output to the DVD decoder
165 XSHD I Header flag signal input from the DVD decoder
166 SDCK I Serial data transfer clock signal input from the DVD decoder
167 XSAK I Serial data effect flag signal input from the DVD decoder
168 SDEF I Error flag signal input from the DVD decoder
169 to 176 SD0 to SD7 I Stream data signal input from the DVD decoder
