SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
EA : Saudi Arabia model
IA : Indonesian model
JE : Tourist model
MY : Malaysia model
SP : Singapore model
TH : Thai model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
HCD-VX555/VX555J
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
1-675-911-14 ADDRESS SENSOR BOARD
*********************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO INTERRUPTER >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
************************************************************
A-4725-561-A BD BOARD, COMPLETE
******************
< CAPACITOR >
C101 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C117 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C120 1-126-607-11 ELECT CHIP 47uF 20% 4V
C151 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C153 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C163 1-117-681-11 ELECT CHIP 100uF 20.00% 16V
C164 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C165 1-124-779-00 ELECT CHIP 10uF 20% 16V
C166 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C182 1-128-995-11 ELECT CHIP 100uF 20% 10V
C201 1-126-246-11 ELECT CHIP 220uF 20% 4V
C202 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C205 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C222 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C224 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C226 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C227 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C228 1-115-156-11 CERAMIC CHIP 1uF 10V
C229 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C231 1-128-995-11 ELECT CHIP 100uF 20% 10V
C234 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C235 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C236 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
< CONNECTOR >
CN101 1-784-875-21 CONNECTOR,FFC(LIF(NON-ZIF))25P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-056-77 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-500-445-21 FERRITE 0UH
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC102 8-759-713-70 IC AN41020A
IC103 8-752-089-74 IC CXA2581N-T4
IC106 8-759-834-29 IC MC74VHC1G04DFT1
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q103 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R102 1-216-077-00 RES-CHIP 15K 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-077-00 RES-CHIP 15K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
ADDRESS SENSOR BD
