Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
71
HCD-VX555/VX555J
1-676-220-11 HEAD (A) BOARD
**************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
************************************************************
1-676-221-11 HEAD (B) BOARD
**************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
************************************************************
A-2007-846-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
************************************************************
A-4476-108-A MAIN BOARD, COMPLETE (VX555:E,MY,SP)
A-2007-978-A MAIN BOARD, COMPLETE (VX555:EA)
A-2007-997-A MAIN BOARD, COMPLETE (VX555:IA)
A-4476-638-A MAIN BOARD, COMPLETE (VX555:TH)
A-4476-608-A MAIN BOARD, COMPLETE (VX555J:EA)
A-4726-174-A MAIN BOARD, COMPLETE (VX555J:JE)
*******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C3 1-104-660-11 ELECT 47uF 20.00% 16V
C4 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C11 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C12 1-104-660-11 ELECT 47uF 20.00% 16V
C13 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C14 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C15 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C16 1-104-660-11 ELECT 47uF 20.00% 16V
C17 1-126-959-11 ELECT 0.47uF 20.00% 50V
C18 1-126-960-11 ELECT 1uF 20.00% 50V
C19 1-126-960-11 ELECT 1uF 20.00% 50V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C22 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C23 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C24 1-126-963-11 ELECT 4.7uF 20.00% 50V
C25 1-126-964-11 ELECT 10uF 20.00% 50V
C26 1-164-471-11 CERAMIC CHIP 680PF 5.00% 50V
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-126-963-11 ELECT 4.7uF 20.00% 50V
C29 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C30 1-126-962-11 ELECT 3.3uF 20.00% 50V
C31 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C32 1-126-963-11 ELECT 4.7uF 20.00% 50V
C35 1-104-660-11 ELECT 47uF 20.00% 16V
C36 1-126-963-11 ELECT 4.7uF 20.00% 50V
C39 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C40 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C41 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C42 1-162-940-11 CERAMIC CHIP 9PF 0.5PF 50V
C43 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C46 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C51 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C52 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C55 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C56 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C57 1-104-660-11 ELECT 47uF 20.00% 16V
C58 1-126-961-11 ELECT 2.2uF 20.00% 50V
C59 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C60 1-104-660-11 ELECT 47uF 20.00% 16V
C61 1-162-974-11 CERAMIC CHIP 0.01uF 50V
HEAD (A) HEAD (B) LEAF SW MAIN
