Sony HCD-VX555 - Page 74

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
74
HCD-VX555/VX555J
D824 8-719-988-61 DIODE 1SS355TE-17
D841 8-719-988-61 DIODE 1SS355TE-17
D861 8-719-988-61 DIODE 1SS355TE-17
D892 8-719-988-61 DIODE 1SS355TE-17
D893 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-080-70 DIODE 11EQS04N-TB5
D902 8-719-080-70 DIODE 11EQS04N-TB5
D903 8-719-080-70 DIODE 11EQS04N-TB5
D904 8-719-080-70 DIODE 11EQS04N-TB5
D906 8-719-083-89 DIODE 11ES2N-TB5
D907 8-719-083-89 DIODE 11ES2N-TB5
D908 8-719-083-89 DIODE 11ES2N-TB5
D909 8-719-083-89 DIODE 11ES2N-TB5
D910 8-719-083-89 DIODE 11ES2N-TB5
D911 8-719-083-89 DIODE 11ES2N-TB5
D912 8-719-083-89 DIODE 11ES2N-TB5
D920 8-719-083-89 DIODE 11ES2N-TB5
D921 8-719-083-89 DIODE 11ES2N-TB5
D922 8-719-083-89 DIODE 11ES2N-TB5
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB201 1-216-864-11 SHORT 0
FB202 1-216-864-11 SHORT 0
FB203 1-216-864-11 SHORT 0
FB204 1-216-864-11 SHORT 0
FB516 1-216-864-11 SHORT 0
FB562 1-216-864-11 SHORT 0
FB599 1-216-864-11 SHORT 0
< FRONT END >
FE1 1-693-477-11 FRONT END (3 GANGS) (EXCEPT VX555J:JE)
FE1 1-693-507-11 FRONT END (3 GANG) (VX555J:JE)
< IC >
IC11 8-759-828-33 IC LA1845
IC51 8-759-584-70 IC LC72131
IC101 8-759-652-04 IC M61504FP-TP
IC102 8-759-106-02 IC uPC4570G2-E2
IC103 8-759-652-01 IC LA2615
IC104 8-759-106-02 IC uPC4570G2-E2
IC105 8-759-525-25 IC BU4052BCF-E2
IC201 8-749-923-04 IC TOTX178A
IC301 8-759-652-80 IC HA12227F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-385-17 IC NJM4580E(TE2)
IC304 8-759-385-17 IC NJM4580E(TE2)
IC501 6-800-179-01 IC M30622MAA-A97FP (VX555/VX555J:EA)
IC501 8-759-829-45 IC M30620MCA-A95FP (VX555J:JE)
IC502 8-759-635-63 IC M51943BSL-TP
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC AN7809
< IFT >
IFT11 1-435-848-11 TRANSFORMER,IF(CERAMIC FILTER)
< JACK >
J101 1-793-987-11 JACK, PIN 2P (MD/VIDEO AUDIO IN)
J102 1-794-472-11 JACK, PIN 2P (SURROUND)
< JUMPER RESISTOR >
JR1 1-216-864-11 SHORT 0
JR2 1-216-864-11 SHORT 0
JR3 1-216-864-11 SHORT 0
JR4 1-216-864-11 SHORT 0
JR5 1-216-864-11 SHORT 0
JR6 1-216-864-11 SHORT 0
JR7 1-216-864-11 SHORT 0
JR8 1-216-864-11 SHORT 0
JR10 1-216-864-11 SHORT 0
JR12 1-216-864-11 SHORT 0
JR15 1-216-864-11 SHORT 0
JR16 1-216-864-11 SHORT 0
JR17 1-216-864-11 SHORT 0
JR18 1-216-864-11 SHORT 0
JR19 1-216-864-11 SHORT 0
JR20 1-216-864-11 SHORT 0
JR21 1-216-864-11 SHORT 0
JR22 1-216-864-11 SHORT 0
JR24 1-216-864-11 SHORT 0
JR25 1-216-864-11 SHORT 0
JR26 1-216-864-11 SHORT 0
JR27 1-216-864-11 SHORT 0
JR28 1-216-864-11 SHORT 0
JR30 1-216-864-11 SHORT 0
JR35 1-216-864-11 SHORT 0
JR301 1-216-864-11 SHORT 0
JR304 1-216-864-11 SHORT 0
JR501 1-216-864-11 SHORT 0
JR620 1-216-864-11 SHORT 0
JR670 1-216-864-11 SHORT 0
JR801 1-216-864-11 SHORT 0
JR805 1-216-864-11 SHORT 0
JR806 1-216-864-11 SHORT 0
JR919 1-216-864-11 SHORT 0
JR922 1-216-864-11 SHORT 0
< COIL >
L101 1-414-189-31 INDUCTOR 100uH
L201 1-414-189-31 INDUCTOR 100uH
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
< TRANSISTOR >
Q1 8-729-055-80 TRANSISTOR 2SC1674LK-TP
Q2 8-729-113-69 TRANSISTOR FN1F4M-T1M32
Q11 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q12 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q101 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
MAIN
