Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
81
HCD-VX555/VX555J
A-4475-781-A POWER BOARD, COMPLETE
(EXCEPT VX555:TH/VX555J)
A-4476-600-A POWER BOARD, COMPLETE (VX555J)
A-4476-630-A POWER BOARD, COMPLETE (VX555:TH)
*******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C502 1-162-286-21 CERAMIC 220PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20.00% 10V
C505 1-162-199-31 CERAMIC 0.1uF 50V
C507 1-136-495-11 FILM 0.068uF 5.00% 50V
C508 1-136-495-11 FILM 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C510 1-128-578-11 ELECT 1uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C512 1-162-306-11 CERAMIC 0.01uF 30% 16V
C513 1-164-159-11 CERAMIC 0.1uF 50V
C514 1-164-159-11 CERAMIC 0.1uF 50V
C544 1-137-749-11 MYLAR 0.1uF 100V
C545 1-137-749-11 MYLAR 0.1uF 100V
C546 1-137-847-11 ELECT 2200uF 20% 71V
C551 1-126-963-11 ELECT 4.7uF 20.00% 50V
C552 1-162-286-21 CERAMIC 220PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20.00% 10V
C555 1-162-199-31 CERAMIC 0.1uF 50V
C557 1-136-495-11 FILM 0.068uF 5.00% 50V
C558 1-136-495-11 FILM 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C581 1-126-967-11 ELECT 47uF 20.00% 50V
C596 1-137-847-11 ELECT 2200uF 20% 71V
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-506-468-11 PIN, CONNECTOR 3P
CN505 1-568-951-11 PIN, CONNECTOR 2P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D543 8-719-302-38 DIODE RBV-602-01
(EXCEPT VX555:TH/VX555J)
D543 8-719-302-37 DIODE RBV-602 (VX555:TH/VX555J)
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-150-92 DIODE MTZJ-T-72-33D
< TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-16 IC STK442-130
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q831 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q941 8-729-141-83 TRANSISTOR 2SB1375
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0 R508 1-217-156-00 METAL 0.22 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0 R510 1-217-156-00 METAL 0.22 20% 5W
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-440-11 CARBON 82K 5% 1/4W
R531 1-249-409-11 CARBON 220 5% 1/4W F
R532 1-247-897-11 CARBON 560K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W F
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0 R558 1-217-156-00 METAL 0.22 20% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
0 R560 1-217-156-00 METAL 0.22 20% 5W
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
POWER
To Next Page
