12
3-9. TRAY (SUB)
3-10. CHASSIS (MOLD B) SECTION, STOCKER SECTION AND
SLIDER (SELECTION)
Note : In mounting the parts, refer to page 12 and 13.
pulley (LD)
stocker
section
tray (sub)
pulley (mode)
slider (selection)
1 Rotating the pulley (LD), shift the slider (selection) in the arrow A direction.
2 Rotating the pulley (mode) in the arrow direction, adjust the tray (sub) to be removed.
3 Rotating the pulley (LD), shift the slider (selection) in the arrow B direction.
4 Rotating the pulley (mode) in the arrow direction, remove the tray (sub) to be removed.
A
B
5 stocker
section
4 two step
screws
4 two step screws
3 gear (eject)
2 chassis (mold B) section
Note: Rotating the pulley (LD),
shift the slider (selection
to the left.
9 compression
spring
7 slider (selection)
8 washer
6 two screws
(PTPWH M2.6)
1 three screws
(BVTP M2.6)
