8-6. BASE UNIT SECTION
(BU-K2BD37A)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
0251 8-820-116-01 OPICAL PICK-UP BLOCK KSM-213DAP/Z-NP
252 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
253 A-4725-001-A BD BOARD, COMPLETE
254 4-951-620-01 SCREW (2.6X8), +BVTP
252
254
253
251
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
