9
3-3. TAPE MECHANISM DECK SECTION (TCM-230AWR12)
AND MIC BOARD
3-4. BACK PANEL SECTION
1 two screws
(BVTP 3 × 8)
2 two screws
(BVTP 3 × 8)
5 two screws
(BVTP 2.6 × 8)
7 two screws
(BVTP 2.6 × 8)
9 MIC board
8
6
4 two knobs (MIC)
3 tape mechanism deck section
(TCM-230AWR12)
2 screw
(BVTP 3 × 8)
3 two screws
(BVTP 3 × 8)
6 screw
(BVTP 3 × 8)
4 five screws
(BVTP 3 × 8)
5 four screws
(BVTP 3 × 8)
7 three screws
(BVTP 3 × 8)
9 three screws
(BVTP 3 × 8)
8 two screws
(BVTP 3 × 8)
qa connector
(CN941)
claws
1 flat type wire (13core)
(CN502)
0 Remove the back panel sectio
in the arrow direction.
