Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C1655 1-162-305-11 CERAMIC 0.0068uF 30.00% 16V
C1656 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C1657 1-126-957-11 ELECT 0.22uF 20.00% 50V
C1658 1-126-957-11 ELECT 0.22uF 20.00% 50V
C1659 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C1660 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1661 1-162-305-11 CERAMIC 0.0068uF 30.00% 16V
C1662 1-126-960-11 ELECT 1uF 20.00% 50V
C1663 1-161-494-00 CERAMIC 0.022uF 25V
C1664 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C1665 1-104-664-11 ELECT 47uF 20.00% 10V
C1666 1-164-159-11 CERAMIC 0.1uF 50V
C1667 1-104-664-11 ELECT 47uF 20.00% 10V
C1668 1-126-961-11 ELECT 2.2uF 20.00% 50V
C1693 1-164-159-11 CERAMIC 0.1uF 50V
< TERMINAL >
* EPT1601 1-537-738-21 TERMINAL, EARTH
< IC >
IC1601 8-759-634-51 IC M5218AP
IC1651 8-759-496-40 IC M65850FP
< JACK >
J1601 1-793-829-11 JACK, HEADPHONE (MIC1)
J1651 1-793-829-11 JACK, HEADPHONE (MIC2)
< RESISTOR >
R1601 1-249-429-11 CARBON 10K 5% 1/4W
R1602 1-249-417-11 CARBON 1K 5% 1/4W F
R1603 1-249-441-11 CARBON 100K 5% 1/4W
R1604 1-249-417-11 CARBON 1K 5% 1/4W F
R1605 1-249-437-11 CARBON 47K 5% 1/4W
R1606 1-249-429-11 CARBON 10K 5% 1/4W
R1607 1-247-885-00 CARBON 180K 5% 1/4W
R1608 1-247-807-31 CARBON 100 5% 1/4W
R1651 1-249-429-11 CARBON 10K 5% 1/4W
R1652 1-249-417-11 CARBON 1K 5% 1/4W F
R1653 1-249-433-11 CARBON 22K 5% 1/4W
R1654 1-249-433-11 CARBON 22K 5% 1/4W
R1655 1-249-433-11 CARBON 22K 5% 1/4W
R1656 1-249-437-11 CARBON 47K 5% 1/4W
R1657 1-249-433-11 CARBON 22K 5% 1/4W
R1658 1-249-433-11 CARBON 22K 5% 1/4W
R1659 1-249-433-11 CARBON 22K 5% 1/4W
R1660 1-249-431-11 CARBON 15K 5% 1/4W
R1661 1-247-881-00 CARBON 120K 5% 1/4W
R1664 1-249-431-11 CARBON 15K 5% 1/4W
< VARIABLE RESISTOR >
RV1601 1-227-171-11 RES, VAR CARBON 50K (MIC VOL)
RV1651 1-227-171-11 RES, VAR CARBON 50K (ECHO VOL)
**************************************************************
1-671-503-11 OUT SW BOARD
*************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
CN715 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MID OUT SW)
S702 1-771-218-11 SWITCH, MICRO (LID SW)
S708 1-771-218-11 SWITCH, MICRO (OUT SW)
**************************************************************
A-4473-001-A PANEL BOARD, COMPLETE (SP,MY,HK,EA)
**********************
A-4473-277-A PANEL BOARD, COMPLETE (TH)
**********************
4-226-723-01 HOLDER (FL)
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C691 1-162-286-31 CERAMIC 220PF 10% 50V
C692 1-162-286-31 CERAMIC 220PF 10% 50V
C701 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C702 1-124-589-11 ELECT 47uF 20% 16V
C703 1-162-290-31 CERAMIC 470PF 10% 50V
C704 1-162-294-31 CERAMIC 0.001uF 10% 50V
C705 1-162-294-31 CERAMIC 0.001uF 10% 50V
C711 1-162-286-31 CERAMIC 220PF 10% 50V
C712 1-162-286-31 CERAMIC 220PF 10% 50V
C713 1-162-286-31 CERAMIC 220PF 10% 50V
C714 1-162-286-31 CERAMIC 220PF 10% 50V
C715 1-162-286-31 CERAMIC 220PF 10% 50V
C716 1-162-286-31 CERAMIC 220PF 10% 50V
C717 1-162-286-31 CERAMIC 220PF 10% 50V
C718 1-162-286-31 CERAMIC 220PF 10% 50V
C719 1-162-286-31 CERAMIC 220PF 10% 50V
C720 1-162-286-31 CERAMIC 220PF 10% 50V
C721 1-162-286-31 CERAMIC 220PF 10% 50V
C722 1-162-286-31 CERAMIC 220PF 10% 50V
C723 1-162-286-31 CERAMIC 220PF 10% 50V
C724 1-162-286-31 CERAMIC 220PF 10% 50V
C725 1-162-286-31 CERAMIC 220PF 10% 50V
C726 1-162-286-31 CERAMIC 220PF 10% 50V
C727 1-162-286-31 CERAMIC 220PF 10% 50V
C728 1-162-286-31 CERAMIC 220PF 10% 50V
C731 1-124-261-00 ELECT 10uF 20% 50V
C732 1-124-261-00 ELECT 10uF 20% 50V
C751 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C752 1-124-589-11 ELECT 47uF 20% 16V
C755 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C756 1-124-261-00 ELECT 10uF 20% 50V
C757 1-162-290-31 CERAMIC 470PF 10% 50V
C761 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C762 1-124-261-00 ELECT 10uF 20% 50V
C763 1-126-163-11 ELECT 4.7uF 20% 50V
C764 1-162-303-11 CERAMIC 0.0033uF 30.00% 16V
C765 1-124-261-00 ELECT 10uF 20% 50V
C766 1-124-261-00 ELECT 10uF 20% 50V
C767 1-124-261-00 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-784-733-11 CONNECTOR, FFC 11P
CN702 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE)8P
CN703 1-785-337-11 PIN, CONNECTOR(LIGHT ANGLE)11P
CN704 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
