Sony MJ620 - 6 Dimensions

(E) 23
MJ620
59 (2.33)
2 (0.079)
(1.5 (0.059)
90 (3.54)
93.5 (3.69)
(5.4 (0.213))
(4 (0.157))
21 (0.83)17 (0.67)
9.6
(0.378)
1.6 (0.063)
12.8
(0.50)
(3.5 (0.138))
7 (0.276)
8 (0.315)8 (0.315)
65 (2.56)
2 (0.079)
3.5 (0.138)
2 (0.079)
(3.5 (0.138))
7.5 (0.295)7.5 (0.295)
4 – Ø3.5 (0.138)
55 (2.17)
48 (1.89)
37 (1.46)
33.4 (1.31)
11 (0.43)
15 (0.59)
Mounting hole
Area occupied by board
and mounted parts
Sensor input conector
Hoshiden: TCS7587-01-401
Output connector
Honda: PCR-E20LMD
6. Dimensions
MJ620
Unit: mm (inch)
