– 10 –
3-8. OPTICAL PICK-UP BLOCK
3-9. MECHANISM DECK
2
Screws (+PWH 2.6x10
)
4
3
3
Chassis
Optical pick-up block
Arm
1
Screws (+PWH 2.6x10)
1
Screws (+BVTT 3x10)
3
2
Cover, deck
Cover ASSY, top
Mechanism deck
1
Screws (+BVTT 3x10
)
