– 8 –
3-4. TRAY
3-5. ASP BOARD
3
Projection
2
1
Tray
3
Projection
Chassis
3
Wire, parallel (16 core)
2
Remove solder
1
Screw (+P 2x6)
4
Chassis
ASP board
