Sony PMC-DR70L - Display Board; DSP Board, CPU Board

– 12 –
3-12. DISPLAY BOARD
3-13. DSP BOARD, CPU BOARD
3 Wire, parallel (19 core)
1 Screws (+BVTT 2.6x8)
4
2 Wire, parallel (18 core)
Holder, Display PC board
DSP board
Display board
CPU boar
d
7 Screws (+BVTT 2.6x8
)
1 Screws (+BVTT 2.6x8)
2 Support
3
8
5
Wire, parallel (18 core)
4 Wire, parallel (14 core)
6 Wire, parallel (19 core)
DSP board
CPU board
Holder, Display PC board
Display board
