– 7 –
3-3. MAIN BOARD, JACK BOARD
3-2. CD ASSY
1
Screws (+BVTT 3x10)
2
Case (bottom)
CD ASSY
2
Screws (+BVTT 2.6x8)
5
3
Case (bottom)
Jack board
Main board
4
Screws (+BVTT 2.6x8)
2
Screws (+BVTT 2.6x8)
1
Screws (+BVTT 3x10
)
