SECTION 2
GENERAL
LOCATION AND FUNCTION OF CONTROLS
MAIN UNIT
2
4
5
!¡!º
@™ @¡ @º
!™
!£
!∞
!¢
!§
!¶
!•
!ª
6
7
8
9
1
3
1 VOLUME +, – buttons
2 CD tray
3 Timer buttons
STANDBY
SLEEP
CLOCK
TIMER
DISPLAY
4 Display window
5 OPERATE button
6 RDS button
7 2 (Headphones) Jack
8 DIR MODE button
9 COUNTER RESET button
!º TAPE operation buttons
r/P (rec/pause)
DUBBING
0, ) (FF, REW)
ª, · (play)
π (stop)
!¡ PLAY MODE, MONO/ST ISS button
!™ ENTER/MEM, PGM SET button
!£ =(–) , +(+) TUNE TIME SET button
!¢ LINE IN button
!∞ SUMER TIME button
!§ MEGA BASS button
!¶ SOUND button
!• 6 CD OPEN/CLOSE button
!ª RADIO operation buttons
PRESET +
BAND
PRESET–
@º CD operation buttons
fl (play/pause)
π (stop)
@¡ SNOOZE button
@™ Remote sensor
