Setup Menu List
47
Menu Configuration and Detailed Settings
The functions and available settings of menus are listed below.
The default settings set at the factory are shown in bold face (example:
Speed). The items marked with
[M] in the Menu items column cannot be set while displaying the thumbnail screen or during playback
operations.
Setup Menu List
[AUDIO SET] Menu
AUDIO SET
Menu items Subitems and setting values Contents
Audio Input
Setting for audio
inputs
(only when audio
input box is
attached)
[M]
Note
This item cannot
be configured
when [i.Link] is
selected for [Input
Source Select] in
the [VIDEO SET]
menu.
CH1 Input Source
SDI IN / Ext
Select the audio signal input source to be recorded as channel
1 for formats that support audio recording.
[SDI IN]: Record the CH-1 signal of the SDI IN connector.
[Ext]: Record the signal selected in [EXT CH Select].
CH2 Input Source
SDI IN / Ext
Select the audio signal input source to be recorded as channel
2 for formats that support audio recording.
[SDI IN]: Record the CH-2 signal of the SDI IN connector.
[Ext]: Record the signal selected in [EXT CH Select].
CH3 Input Source
SDI IN / Ext
Select the audio signal input source to be recorded as channel
3 for formats that support 4-channel audio recording.
[SDI IN]: Record the CH-3 signal of the SDI IN connector.
[Ext]: Record the signal selected in [EXT CH Select].
CH4 Input Source
SDI IN / Ext
Select the audio signal input source to be recorded as channel
4 for formats that support 4-channel audio recording.
[SDI IN]: Record the CH-4 signal of the SDI IN connector.
[Ext]: Record the signal selected in [EXT CH Select].
EXT CH Select
CH1/CH2 / CH1
Set the signal settings that are selected when [Ext] is selected
for [CH1 Input Source] to [CH4 Input Source].
[CH1/CH2]: Input the audio signal from the CH-1 AUDIO IN
connector to the odd-numbered channel for which [Ext] is
selected, and input the audio signal from the CH-2 AUDIO
IN connector to the even-numbered channels.
[CH1]: Input the audio signal from the CH-1 AUDIO IN
connector to all the channels for which [Ext] is selected.
Line Input Ref
+4dB / 0dB / –3dB / EBUL
Set the reference input level that is used when the input source
is set to [Ext] in [CH1 Input Source] to [CH4 Input Source].
The same setting is used for both CH-1 and CH-2 of the
AUDIO connector.
Tip
This setting is only enabled when the input source is set to
[Ext].
Reference Level
-20dB / –18dB / –16dB /
–12dB / EBUL
Set the output level of the 1 kHz test signal.
Tip
This setting is only enabled when the input source is set to
[Ext].
To Next Page
