Changing Basic Settings
21
Recording
To record or output a signal, either SDI or i.LINK
must be selected as the input signal source. The
setting is made in [Input Source Select] in the
[VIDEO SET] menu.
If i.LINK is selected, output to i.LINK is not
possible.
In UDF/HD mode and exFAT mode, i.LINK
cannot be selected.
Switching between UDF/exFAT/FAT
Switch by setting [F.Sys.] under [System] (page
57) in the [OTHERS] menu.
After switching this setting, the recorder will
automatically restart.
Switching between HD Mode/SD Mode
For [HD/SD] switching, use [System] (page 57)
in the [OTHERS] menu.
When you change the menu setting, the recorder
automatically restarts, executing the switching.
Note
[UDF/exFAT/FAT] and [HD/SD] switching is disabled
during recording and playback.
Switching between XAVC/MPEG2
Switch by setting [XAVC/MPEG2] under
[System] (page 57) in the [OTHERS] menu.
This can be selected when [F.Sys.] is set to
[exFAT] and [HD/SD] is set to [HD].
Note
You cannot switch between XAVC/MPEG2 during
recording or playback.
Changing the format
The format of the input signal connected to the
SDI IN connector must match the video format
set in [Rec Format] (page 58) in the [OTHERS]
menu.
The format of the signals output from the SDI
OUT 1/2, VIDEO OUT, and HDMI OUT
connectors changes according to the video format
setting.
Selectable formats vary depending on the UDF/
exFAT/FAT, HD/SD, and usage region (NTSC/
PAL) settings (page 57).
The supported video format settings and
corresponding supported input formats are shown
below.
For details about the output signal format, see
“Formats and Limitations of Outputs” (page 76).
For NTSC
UDF/HD mode
exFAT/HD mode
Recording
Changing Basic Settings
Selecting an Input Signal
Video Formats
[Rec Format] setting Input signal format
HD422 50/1080/59.94i 1080/59.94i, 1080/
29.97PsF
HQ 1920×1080/59.94i 1080/59.94i, 1080/
29.97PsF
HQ 1440×1080/59.94i 1080/59.94i, 1080/
29.97PsF
HD422 50/1080/29.97P 1080/59.94i, 1080/
29.97PsF
HQ 1920×1080/29.97P 1080/59.94i, 1080/
29.97PsF
HQ 1440×1080/29.97P 1080/59.94i, 1080/
29.97PsF
HD422 50/1080/23.98P 1080/23.98PsF
HQ 1920×1080/23.98P 1080/23.98PsF
HQ 1440×1080/23.98P 1080/23.98PsF
HD422 50/720/59.94P 720/59.94P
HQ 1280×720/59.94P 720/59.94P
[Rec Format] setting Input signal format
XAVC-I 1080/59.94P 1080/59.94P
XAVC-L50 1080/59.94P 1080/59.94P
XAVC-L35 1080/59.94P 1080/59.94P
XAVC-I 1080/59.94i 1080/59.94i, 1080/
29.97PsF
XAVC-L50 1080/59.94i 1080/59.94i, 1080/
29.97PsF
XAVC-L35 1080/59.94i 1080/59.94i, 1080/
29.97PsF
XAVC-L25 1080/59.94i 1080/59.94i, 1080/
29.97PsF
To Next Page
