Setup Menu List
49
Menu Configuration and Detailed Settings
Audio Output
Setting for audio
outputs
1KHz Tone
On / Off
Turn the 1-kHz reference tone signal on/off.
Monitor CH
CH-1/CH-2 (CH-3/CH-4)
CH-1+CH-2 (CH-3+CH-4)
CH-1 (CH-3)
CH-2 (CH-4)
Select the audio channel(s) to be fed to the headphones and
the built-in speaker.
[CH-1/CH-2 (CH-3/CH-4)]: Stereo
[CH-1+CH-2 (CH-3+CH-4)]: Mix
[CH-1 (CH-3)]: CH-1 (CH-3) only
[CH-2 (CH-4)]: CH-2 (CH-4) only
( ): with [Output CH] set to [CH-3/CH-4]
Output CH
CH-1/CH-2
CH-3/CH-4
Select audio output channels from either channels 1 and 2 or
channels 3 and 4.
Alarm Level
0 to 7 (4)
Set the alarm sound volume.
AUDIO SET
Menu items Subitems and setting values Contents
[VIDEO SET] Menu
VIDEO SET
Menu items Setting values Contents
Input Source
Select
Setting the input
source
SDI / i.LINK Select video and audio signal for the input source.
[SDI]: Input from SDI IN connector
[i.LINK]: HDV/DVCAM input via the i.LINK connector
Note
i.LINK is unavailable in UDF/HD mode and exFAT mode.
Color Bars On/
Off
Setting the Color
Bars
On / Off Turn color bars output on/off when [Input Source Select] is
set to [SDI].
Color Bars
Type
Selecting the type
of color bars
Multi / 75% / 100% / SMPTE Select the type of color bars to be output when [Color Bars
On/Off] is set to [On].
[Multi]: Multiformat color bars are output.
[75%]: To output 75% color bars
[100%]: To output 100% color bars
[SMPTE]: To output SMPTE color bars.
To Next Page
