Setup Menu List
51
Menu Configuration and Detailed Settings
3G SDI OUT
Level A/B
Setting the 3G SDI
output signal
format
LevelA / LevelB Select the data mapping method for 3G SDI output signals.
Tips
• Support for Level A is planned for future updates.
• This setting is only enabled when the [SDI/HDMI/i.LINK
I/O Select] is set to [3G (SDI)].
SDI/HDMI/
Video Out
Super
Setting the
character
information for
each output
On / Off Set whether to add the menus and status indications of the
LCD monitor to the output of the SDI OUT 1/2, HDMI OUT,
and VIDEO OUT connectors.
Note
On the thumbnail, EXPAND CLIP and SHOT MARK
screens, the menus and status indications on the LCD monitor
are displayed regardless of the setting of this item.
Down
Converter
Selecting the
operation mode of
the down converter
Squeeze / Letterbox / Edge
Crop
Set the output mode (aspect) for SD signals
[Squeeze]: To horizontally reduce a 16:9 picture to output a
4:3 picture
[Letterbox]: To mask the upper and lower areas of a 4:3
picture to display a 16:9 picture in the center of the screen
[Edge Crop]: To cut the both sides of a 16:9 picture to output
a 4:3 picture
23.98P Output
Selecting Output
mode
59.94i (2-3PD)/ 23.98PsF Select the output format for the following video formats.
For UDF/HD mode: HD422 50/1080/23.98P, HQ 1920×1080/
23.98P, HQ 1440×1080/23.98P
For exFAT/HD mode: XAVC-I 1080/23.98P, XAVC-L50
1080/23.98P, XAVC-L35 1080/23.98P, HD422 50/1080/
23.98P, HQ 1920×1080/23.98P, HQ 1440×1080/23.98P
For FAT/HD mode: HQ 1920×1080/23.98P, HQ 1440×1080/
23.98P
SDI Rec
Control
Setting the
synchronized
recording
Off / On Select whether to start/stop recording in synchronization with
an REC trigger signal sent from the device connected to the
SDI IN connector.
Clip Cont. Rec
Setting
Setting the Clip
Continuous
Recording
function
On / Off Turn the Clip Continuous Recording function on/off.
Segment Loop
Rec
Setting loop
recording
On / Off Turn loop recording using two SxS memory cards on/off.
Segment
Duration
Setting loop
recording retention
time
15~35min / 30~65min Set the retention time of video during loop recording. Cannot
be selected if the remaining recording time of the SxS
memory cards is less than the capacity required for recording.
VIDEO SET
Menu items Setting values Contents
To Next Page
