Sony SA-WS700RF - Printed Wiring Board - Main Board

HT-S500RF/S700RF
HT-S500RF/S700RF
24
Sony CONFIDENTIAL
For Authorized Servicer
5-2. PRINTED WIRING BOARD - MAIN Board (SA-WS500RF/WS700RF) -
• : Uses unleaded solder.
• See page 23 for Circuit Boards Location.
MAIN BOARD (CONDUCTOR SIDE)
MAIN BOARD (COMPONENT SIDE)
A
B
C
D
1 2 3 4 5 6 7 8 9
Note: When the U16, U17 or U18 on the MAIN board is replaced,
spread the compound to the touching portion between the U16,
U17, U18 and the heat sink.
