Sony SA-WS700RF - Printed Wiring Board; TOUCH Board (SA-WS500 RF;WS700 RF); Schematic Diagram - TOUCH Board (SA-WS500 RF;WS700 RF); POWER Board (SA-WS500 RF;WS700 RF)

HT-S500RF/S700RF
HT-S500RF/S700RF
36
Sony CONFIDENTIAL
For Authorized Servicer
5-17. PRINTED WIRING BOARD - TOUCH Board (SA-WS500RF/WS700RF) -
• : Uses unleaded solder.
• See page 23 for Circuit Boards Location.
A
B
1 2 3 4 5 6 7
TOUCH BOARD (SIDE A)
TOUCH BOARD (SIDE B)
5-18. SCHEMATIC DIAGRAM - TOUCH Board (SA-WS500RF/WS700RF) -
TC_INT
TC_CLK
TC_INT
TC_SDATC_SDA
TC_CLK
POWER
source
bt vol+
vol-
TC_3V3
TC_3V3
TP2
100pF/50V/NP0
5.6K
33
33
100pF/50V/NP0
5.6K
5PIN/1.0mm
1
2
3
4
5
TP1
0.1UF
5.6K
33
1UF
4700pF
100pF/50V/NP0
5.6K
AS9050
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
5.6K
10uF
C3
R8
R1
R2
PAD4
C7
R7
XP1
C5
R6
R3
PAD2 PAD1
C2
C1
C4
R5
U1
PAD3 PAD5
R4
C6
1
2
3
4
5
SDA
SCL
SNS9
SNS8
PC7
PC6
PC5
PC4 PC3
PC2
PC1
PC0
VCC
VD
VSS
COUT
A
B
C
12345
TOUCH BOARD
5-19. PRINTED WIRING BOARD - POWER Board (SA-WS500RF/WS700RF) -
• : Uses unleaded solder.
• See page 23 for Circuit Boards Location.
POWER BOARD (COMPONENT SIDE)
POWER BOARD (CONDUCTOR SIDE)
A
B
C
D
E
F
G
H
I
1 2 3 4 5 6 7
SYSSET
2018/11/2806:27:54(GMT+09:00)
