Sony SA-WS700RF - Subwoofer AMP Section (SA-WS500 RF)

43
HT-S500RF/S700RF
Sony CONFIDENTIAL
For Authorized Servicer
6-2. SUBWOOFER AMP SECTION (SA-WS500RF)
Note 1: Refer to page 45 for the SA-WS700RF.
G
G
H
H
I
I
J
J
K
K
FFC2
FAN1
AC1
WR1
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not
supplied
#1
#1
#1
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
not
supplied
51
51
51
51
52
52
52
52
53
54
55
56
57
57
57
57
not supplied
Note 2: When the complete BT board (Ref. No. 55) is replaced, refer
to “OPERATION CHECK OF THE BLUETOOTH CONNEC-
TION” on page 7.
51 9-885-223-41 CATCHER RUBBER
52 9-885-223-91 SCREW +BVTT 3X16 (S)
53 9-885-223-25 POWER BOARD, COMPLETE (Including Cushion)
(CH, E3, EA, SP, AR, IND)
53 9-885-223-26 POWER BOARD, COMPLETE (Including Cushion)
(LA)
54 9-885-223-18 MAIN BOARD, COMPLETE
55 9-885-223-83 BT BOARD, COMPLETE (IND) (See Note 2)
55 9-885-223-84 BT BOARD, COMPLETE (CH, E3, EA, SP)
(See Note 2)
55 9-885-223-85 BT BOARD, COMPLETE (AR, LA) (See Note 2)
56 9-885-223-39 SPK JACK BOARD, COMPLETE
57 9-885-223-40 SCREW SW
0 AC1 9-885-223-27 POWER CORD (EK E12) (IND)
0 AC1 9-885-223-28 POWER CORD (EK EURO) (E3, SP, LA)
0 AC1 9-885-223-29 POWER CORD (EK1 CN4) (CH)
0 AC1 9-885-223-30 POWER CORD (EK EA4) (EA)
0 AC1 9-885-223-31 POWER CORD (EK1 AR2) (AR)
0 FAN1 9-885-223-51 DC FAN
FFC2 9-885-223-48 FFC (BT) (24 core)
WR1 9-885-223-55 CABLE (MAIN SPK JACK) (10 pin)
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ver. 1.1
