8-7
R3508 1-249-437-11 CARBON 47K 5% 1/4W
(E220UY)
R3516 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R3517 1-216-089-00 METAL CHIP 47K 5% 1/10W
R3518 1-249-437-11 CARBON 47K 5% 1/4W
R3520 1-216-111-00 METAL CHIP 390K 5% 1/10W
R3521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R3525 1-249-417-11 CARBON 1K 5% 1/4W
R3526 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R3527 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R3528 1-249-442-11 CARBON 510 5% 1/4W
R3529 1-249-442-11 CARBON 510 5% 1/4W
R3533 1-249-419-11 CARBON 1.5K 5% 1/4W
(E220UY)
R3537 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R3546 1-249-425-11 CARBON 4.7K 5% 1/4W
R3547 1-208-810-11 METAL GLAZE 15K 1% 1/10W
R3549 1-216-073-00 METAL CHIP 10K 5% 1/10W
R3550 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R3551 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E270 & E280 Series)
R3552 1-216-097-00 METAL CHIP 100K 5% 1/10W
(E270 & E280 Series)
R3553 1-247-887-00 CARBON 220K 5% 1/4W
(E270 & E280 Series)
R3555 1-216-097-00 METAL CHIP 100K 5% 1/10W
(E270 & E280 Series)
R3556 1-216-073-00 METAL CHIP 10K 5% 1/10W
R3557 1-216-109-00 METAL CHIP 330K 5% 1/10W
R3558 1-216-041-11 METAL GLAZE 470 5% 1/10W
R3560 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R3581 1-249-438-11 CARBON 56K 5% 1/4W
(E220UY)
R5001 1-202-724-00 SOLID 2.7M 10% 1/2W
R5002 1-216-031-00 METAL CHIP 180 5% 1/10W
R5003 1-249-420-11 CARBON 1.8K 5% 1/4W
R5004 1-216-109-00 METAL CHIP 330K 5% 1/10W
R5005 1-216-295-11 METAL CHIP 0 5% 1/10W
R5006 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5007 1-216-081-00 METAL CHIP 22K 5% 1/10W
R5009 1-216-093-11 METAL GLAZE 68K 5% 1/10W
R5010 1-247-893-11 CARBON 390K 5% 1/4W
R5011 1-247-893-11 CARBON 390K 5% 1/4W
R5020 1-215-903-11 METAL OXIDE 68K 5% 2W
R5021 1-215-903-11 METAL OXIDE 68K 5% 2W
R5101 1-249-411-11 CARBON 330 5% 1/4W
R5102 1-216-039-00 METAL CHIP 390 5% 1/10W
R5103 1-249-414-11 CARBON 560 5% 1/4W
R5104 1-249-423-11 CARBON 3.3K 5% 1/4W
R5105 1-249-409-11 CARBON 220 5% 1/4W
R5106 1-249-413-11 CARBON 470 5% 1/4W
R5108 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5109 1-249-423-11 CARBON 3.3K 5% 1/4W
R5110 1-212-867-00 FUSIBLE 27 5% 1/4W
R5111 1-249-442-11 CARBON 510 5% 1/4W
R5112 1-216-063-00 METAL CHIP 3.9K 5% 1/10W
R5114 1-249-401-11 CARBON 47 5% 1/4W
R5120 1-249-668-11 CARBON 8.2 5% 1/4W
R5121 1-249-386-11 CARBON 2.7 5% 1/4W
R5123 1-249-420-11 CARBON 1.8K 5% 1/4W
R5132 1-249-423-11 CARBON 3.3K 5% 1/4W
R5133 1-249-428-11 CARBON 8.2K 5% 1/4W
R5134 1-249-423-11 CARBON 3.3K 5% 1/4W
R5135 1-216-027-00 METAL CHIP 120 5% 1/10W
< TRANSFORMER >
T2001 1-431-150-11 TRANSFORMER, OSC 70KHz
T5001 1-431-151-11 TRANSFORMER, PULSE POWER
< VARIABLE RESISTOR >
VR351 1-228-998-00 RES, ADJ, METAL 220K (SW-P)
< VIBRATOR >
X1001 1-760-652-11 CRYSTAL OSC (4.433619MHz)
X1401 1-760-047-11 CRISTAL (17.734476MHz)
(EXCEPT E120AE,E220 Series)
X3001 1-760-653-11 CERAMIC OSC (8.5MHz)
X3002 1-579-220-11 CRYSTAL, OSC (32KHz)
A-6796-534-A MC-1 BOARD, COMPLETE
*********************
< CAPACITOR >
C8001 1-161-063-00 CERAMIC 0.1uF 10% 50V
< RESISTOR >
R8001 1-249-420-11 CARBON 1.8K 5% 1/4W
R8002 1-249-416-11 CARBON 820 5% 1/4W
R8003 1-249-410-11 CARBON 270 5% 1/4W
R8004 1-249-407-11 CARBON 150 5% 1/4W
< SWITCH >
S8002 1-762-173-11 SWITCH, EP (1P-1T) (EP SW)
* A-6796-532-A TM-1 BOARD, COMPLETE
*********************
* 3-966-986-01 HOLDER, IR
* 3-958-684-01 HOLDER, FL
< FLUORESCENT INDICATOR >
A7101 1-517-647-11 TUBE, FLUORESCENT INDICATOR
< CAPACITOR >
C7101 1-164-073-11 CERAMIC 100PF 10% 50V
C7103 1-164-073-11 CERAMIC 100PF 10% 50V
C7104 1-164-073-11 CERAMIC 100PF 10% 50V
C7113 1-124-259-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN711 1-251-523-11 SOCKET, FFC (37P)
CN712 1-251-524-11 SOCKET, RIBBON (5P)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board.
MC-1
CP-A TM-1
To Next Page
