Sony SLV-E120AE - VP-1

8-8
< DIODE >
D7103 8-719-301-58 LED SEL2910D-D (OPC)
D7104 8-719-301-58 LED SEL2910D-D (ATR)
D7112 8-719-991-33 DIODE 1SS133T-77
D7113 8-719-991-33 DIODE 1SS133T-77
D7114 8-719-991-33 DIODE 1SS133T-77
D7115 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q7101 8-729-140-97 TRANSISTOR KSA708
Q7102 8-729-900-80 TRANSISTOR DTC114ES
Q7103 8-729-900-80 TRANSISTOR DTC114ES
Q7104 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R7101 1-249-433-11 CARBON 22K 5% 1/4W
R7102 1-249-421-11 CARBON 2.2K 5% 1/4W
R7103 1-249-407-11 CARBON 150 5% 1/4W
R7104 1-249-408-11 CARBON 180 5% 1/4W
< RECEIVER PACK >
RR711 1-475-047-11 RECEIVER PACK UNIT, IR
< SWITCH >
S7101 1-762-303-11 SWITCH, PUSH (1P-1T)(ALL CLEAR)
S7111 1-762-303-11 SWITCH, PUSH (1P-1T)(CH +)
S7112 1-762-303-11 SWITCH, PUSH (1P-1T)(CH –)
S7114 1-762-303-11 SWITCH, PUSH (1P-1T)(ATR)
S7115 1-762-303-11 SWITCH, PUSH (1P-1T)(PAUSE)
S7116 1-762-303-11 SWITCH, PUSH (1P-1T)(STOP)
S7118 1-762-303-11 SWITCH, PUSH (1P-1T)(PRESET)
S7119 1-762-303-11 SWITCH, PUSH (1P-1T)(REW)
S7120 1-762-303-11 SWITCH, PUSH (1P-1T)(PLAY)
S7121 1-762-303-11 SWITCH, PUSH (1P-1T)(ERASE)
S7122 1-762-303-11 SWITCH, PUSH (1P-1T)(SEARCH)
S7123 1-762-303-11 SWITCH, PUSH (1P-1T)(FF)
S7124 1-762-303-11 SWITCH, PUSH (1P-1T)(REC)
S7125 1-762-303-11 SWITCH, PUSH (1P-1T)(TR +)
S7126 1-762-303-11 SWITCH, PUSH (1P-1T)(TR –)
* A-6796-533-A TM-2 BOARD, COMPLETE(E280 Series)
* A-6796-541-A TM-2 BOARD, COMPLETE(E220 & E270 Series)
* A-6796-633-A TM-2 BOARD, COMPLETE(E120AE)
*********************
* 3-947-425-01 HOLDER, LED
< CAPACITOR >
C7221 1-162-286-31 CERAMIC 220PF 10% 50V
(E280 Series)
< CONNECTOR >
CN722 1-251-525-11 SOCKET, RIBBON (4P) (E280 Series)
< DIODE >
D7201 8-719-301-58 LED SEL2910D-D (POWER)
D7202 8-719-301-58 LED SEL2910D-D (POWER)
< RESISTOR >
R7201 1-249-408-11 CARBON 180 5% 1/4W
R7202 1-249-408-11 CARBON 180 5% 1/4W
R7221 1-247-804-11 CARBON 75 5% 1/4W
(E280 Series)
R7222 1-249-417-11 CARBON 1K 5% 1/4W
(E280 Series)
< SWITCH >
S7201 1-762-303-11 SWITCH, PUSH (1P-1T) (POWER)
S7202 1-762-303-11 SWITCH, PUSH (1P-1T) (EJECT)
* A-6796-530-A TM-9 BOARD, COMPLETE
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
*********************
< CAPACITOR >
C7701 1-130-489-11 MYLAR 0.033uF 5% 50V
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
C7702 1-161-375-00 CERAMIC 0.0022uF 20% 50V
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
C7703 1-136-171-00 FILM 0.33uF 5% 50V
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
C7704 1-162-284-31 CERAMIC 150PF 10% 50V
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
C7705 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
< CONNECTOR >
CN771 1-778-864-11 CONNECTOR (5P)
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
< IC >
IC771 1-810-868-11 IC SDA5649
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
< RESISTOR >
R7701 1-216-069-11 METAL GLAZE 6.8K 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7702 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7703 1-216-069-11 METAL GLAZE 6.8K 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7704 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7705 1-216-121-00 METAL CHIP 1M 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7706 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7707 1-216-097-00 METAL CHIP 100K 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
R7708 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E220VP1,VP2,E270VC1,VC2,E280UX,VC1,VC2)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
When indicating parts by reference
number, please include the board.
TM-1
TM-2
TM-9
