8-9
* A-6796-558-A VP-1 BOARD, COMPLETE(E220UY,E280 Series)
* A-6796-535-A VP-1 BOARD, COMPLETE
(E120AE,E220AE,VP1,VP2,E270 Series)
*********************
< CAPACITOR >
C1805 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1806 1-102-129-00 CERAMIC 10000PF 10% 50V
C1807 1-126-154-11 ELECT 47uF 20% 6.3V
C1808 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1809 1-126-301-11 ELECT 1uF 20% 50V
C1810 1-102-129-00 CERAMIC 10000PF 10% 50V
C1812 1-162-207-31 CERAMIC 22PF 5% 50V
C1813 1-162-207-31 CERAMIC 22PF 5% 50V
C1835 1-102-129-00 CERAMIC 10000PF 10% 50V
C1836 1-161-055-00 CERAMIC 0.022uF 10% 50V
< CONNECTOR >
CN182 1-251-433-11 SOCKET (FFC 5P)
< IC >
IC181 1-801-705-11 IC LA70002L
< RESISTOR >
R1801 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1802 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(E220UY,E280 Series)
R1802 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(E120AE,E220AE,VP1,VP2,E270 Series)
R1804 1-216-045-00 METAL CHIP 680 5% 1/10W
R1806 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R1807 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R1831 1-216-295-11 METAL CHIP 0 5% 1/10W
R1833 1-216-295-11 METAL CHIP 0 5% 1/10W
MISCELLANEOUS
***************
8 1-693-358-11 TUNER (RF/TU/IF)(EXCEPT E220UY,E280UX)
8 1-693-375-11 TUNER (RF/TU/IF)(E220UY,E280UX)
25 1-777-958-11 CABLE, FLEXIBLE FLAT
52 1-698-912-11 MOTOR, ROTOR CYL DC 2W
54 1-698-913-11 MOTOR, STATOR CYL DC 2W
104 1-810-691-11 PHOTO DIODE PN263L-NC
110 1-810-690-11 LED LN59L
111 1-801-326-11 PHOTO COUPLER SG-105F
169 1-698-579-11 MOTOR, CAPSTAN DC 3W(E270 & E280 Series)
169 1-698-590-11 MOTOR, CAPSTAN DC 3W(E120AE,E220 Series)
ACCESSORIES & PACKING MATERIALS
********************************
1-475-037-41 COMMANDER, STANDARD(RMT-V206C)
(E280CP,VC1,VC2)
1-475-037-51 COMMANDER, STANDARD (RMT-V206D)
(E280UX)
1-475-038-41 COMMANDER, STANDARD(RMT-V207C)
(E220VP1,VP2)
1-475-038-51 COMMANDER, STANDARD(RMT-V207D)
(E220AE)
1-475-038-61 COMMANDER, STANDARD(RMT-V207E)
(E220UY)
1-475-039-21 COMMANDER, STANDARD(RMT-V207G)
(E120AE)
1-475-040-11 COMMANDER, STANDARD(RMT-V207H)
(E270 Seris)
! 1-590-866-11 CORD, POWER (EXCEPT E220UY,E280UX)
! 1-590-866-12 CORD, POWER (E220UY,E280UX)
3-709-128-00 COVER, BATTERY
3-749-104-01 CABLE, ANT (PAL) (E270VC1,VC2,E280 Series)
3-858-757-11 MANUAL (E280), INSTRUCTION(English)
(E280UX)
3-858-758-11 MANUAL (E280), INSTRUCTION(Italian)
(E280CP,VC1)
3-858-759-11 MANUAL (E280), INSTRUCTION(French)
(E280VC1)
3-858-760-11 MANUAL (E280), INSTRUCTION(German)
(E280VC1)
3-858-761-11 MANUAL (E280), INSTRUCTION(Dutch)
(E280VC1)
3-858-762-11 MANUAL (E220), INSTRUCTION(Danish)
(E220VP2)
3-858-763-11 MANUAL (E220), INSTRUCTION(Finnish)
(E220VP2)
3-858-764-11 MANUAL (E120), INSTRUCTION(Italian)
(E120AE)
3-858-765-11 MANUAL (E120), INSTRUCTION(French)
(E120AE)
3-858-766-11 MANUAL (E120), INSTRUCTION(German)
(E120AE)
3-858-767-11 MANUAL (E120), INSTRUCTION(Dutch)
(E120AE)
3-858-768-11 MANUAL (E120), INSTRUCTION(Spanish)
(E120AE)
3-858-769-11 MANUAL (E120), INSTRUCTION(Portuguese)
(E120AE)
3-858-770-11 MANUAL (E280), INSTRUCTION(Swedish)
(E280VC2)
3-858-771-11 MANUAL (E280), INSTRUCTION(Danish)
(E280VC2)
3-858-772-11 MANUAL (E280), INSTRUCTION(Finnish)
(E280VC2)
3-858-773-11 MANUAL (E280), INSTRUCTION(Portuguese)
(E280VC2)
3-858-774-11 MANUAL (E280), INSTRUCTION(Spanish)
(E280CP)
3-858-776-11 MANUAL (E270), INSTRUCTION(French)
(E270VC1)
3-858-777-11 MANUAL (E270), INSTRUCTION(German)
(E270VC1)
3-858-778-11 MANUAL (E270), INSTRUCTION(Spanish)
(E270CP)
3-858-780-11 MANUAL (E220), INSTRUCTION(English)
(E220UY)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board.
VP-1
To Next Page
