104
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
D540 8-719-988-61 DIODE 1SS355TE-17
D541 8-719-988-61 DIODE 1SS355TE-17
D542 8-719-988-61 DIODE 1SS355TE-17
D543 8-719-988-61 DIODE 1SS355TE-17
D544 8-719-988-61 DIODE 1SS355TE-17
D545 8-719-988-61 DIODE 1SS355TE-17
D546 8-719-988-61 DIODE 1SS355TE-17
D598 8-719-988-61 DIODE 1SS355TE-17
D607 8-719-988-61 DIODE 1SS355TE-17
D667 8-719-988-61 DIODE 1SS355TE-17
< COIL >
L501 1-422-009-13 COIL, AIR-CORE
L551 1-422-009-13 COIL, AIR-CORE
L651 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q598 8-729-230-49 TRANSISTOR 2SC2712-YG
Q611 8-729-230-49 TRANSISTOR 2SC2712-YG
Q621 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R511 1-249-389-11 CARBON 4.7 5% 1/4W
R512 1-249-393-11 CARBON 10 5% 1/4W
R561 1-249-389-11 CARBON 4.7 5% 1/4W
R562 1-249-393-11 CARBON 10 5% 1/4W
R584 1-249-393-11 CARBON 10 5% 1/4W
R585 1-216-073-00 RES-CHIP 10K 5% 1/10W
R586 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R589 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R617 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R632 1-216-073-00 RES-CHIP 10K 5% 1/10W
R633 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R634 1-249-393-11 CARBON 10 5% 1/4W
R642 1-216-073-00 RES-CHIP 10K 5% 1/10W
R644 1-249-393-11 CARBON 10 5% 1/4W
R645 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R655 1-249-389-11 CARBON 4.7 5% 1/4W
R683 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R698 1-249-393-11 CARBON 10 5% 1/4W
R733 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
< RELAY >
RY503 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY661 1-515-920-11 RELAY (24V)
< TERMINAL >
TM501 1-694-935-11 TERMINAL BOARD (8P) (SPEAKERS,FRONT A/B)
(DA4ES/DA7ES)
TM501 1-694-935-21 TERMINAL BOARD (8P) (SPEAKERS,FRONT A/B)
(VA333ES)
TM601 1-694-910-11 TERMINAL BOARD (2P) (SPEAKERS,CENTER)
(DA4ES/DA7ES)
TM601 1-694-910-21 TERMINAL BOARD (2P) (SPEAKERS,CENTER)
(VA333ES)
*************************************************************
1-685-487-11 FUNCTION BOARD
***************
< CONNECTOR >
CNP106 1-784-922-11 PIN, CONNECTOR 5P
< DIODE >
D116 8-719-032-98 LED SEL5820A (AUDIO SPLIT)
< RESISTOR >
R165 1-216-029-00 METAL CHIP 150 5% 1/10W
R166 1-216-049-11 RES-CHIP 1K 5% 1/10W
R167 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
< ROTARY ENCODER >
RV101 1-467-808-21 ENCODER, ROTARY (FUNCTION)
< SWITCH >
S132 1-771-349-21 SWITCH, KEYBOARD (AUDIO SPLIT)
S133 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
S134 1-771-349-21 SWITCH, KEYBOARD (MUTING)
*************************************************************
1-685-488-11 HP BOARD
*********
< CAPACITOR >
C120 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
(VA333ES)
C121 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
(VA333ES)
< CONNECTOR >
CNP109 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CNP111 1-779-978-11 PIN, CONNECTOR 3P
< JACK >
J101 1-815-313-21 JACK (PHONES)
*************************************************************
A-4728-880-A INPUT BOARD, COMPLETE (DA4ES)
A-4728-893-A INPUT BOARD, COMPLETE (VA333ES)
A-4728-915-A INPUT BOARD, COMPLETE (DA7ES)
**********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 (DA4ES/DA7ES)
< CAPACITOR >
C301 1-119-821-11 ELECT 2.2uF 20% 50V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C303 1-128-832-11 ELECT 220uF 20% 10V
C304 1-125-896-11 MYLAR 0.0091uF 5% 50V
C305 1-136-159-00 MYLAR 0.033uF 5% 50V
C306 1-126-045-11 ELECT 2.2uF 20% 50V
C308 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
F-SPTM INPUTHPFUNCTION
