Sony STR-DA7ES - 4-4. Back Panel Section; 4-5. Digital Board

14
STR-DA4ES/DA7ES/VA333ES
4-4. BACK PANEL SECTION
4-5. DIGITAL BOARD
qg five screws
(BV 3x8 CU)
qh five screws
(BV 3x8 CU)
qj two screws
(fedder fixed)
qd two screws (BV 3x8 CU)
qf two screws (BVTT 4x8)
qk CNP506
ql CNP507
w; CN903
wa CNP651
ws CN1001
wg back panel section
wf CNP52
1 CNP204
2 CN2101
3 CN2105
4 CN2104
5 CN2103
wd CNP51
6 CNP810
8 CNP504
9 CNP503
0 CN504
qa CNP702
qs CNP509
7 CN801
2 two screws
(BV 3x8 CU
)
5
3
two screws
(BV 3x8 CU)
4 two screws
(BV 3x8 CU)
1 CN2102
6 CN1701
7 CN1803
8 CN1601
9 CN1602
0 CN1801
qa CN1802
qs DIGITAL board
